GL2400B8
GLOBAL
8517710000
10pc
Accepted
1000PC/Day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications Frequency Range (MHz) 2400-2500 Horizontal beam width(°) 360 Vertical beam width (°) 17±3° Gain (dBi) 8±1 VSWR ≤1.5 Maximum input power (W) 100 Impedance (Ω) 50 Mechanical Specifications Dimensions (mm) Ø25/32*600mm Antenna weight (Kg) 0.2 Radome material fiberglass Radome color black Input connector type N male
Electrical Specifications Frequency Range (MHz) 2400-2500 Horizontal beam width(°) 360 Vertical beam width (°) 17±3° Gain (dBi) 8±1 VSWR ≤1.5 Maximum input power (W) 100 Impedance (Ω) 50 Mechanical Specifications Dimensions (mm) Ø25/32*600mm Antenna weight (Kg) 0.2 Radome material fiberglass Radome color black Input connector type N male
