Premium patch antennas at AsiaLeren – your reliable source for compact, high-gain wireless solutions engineered for modern connectivity. Whether you're deploying IoT devices, base stations, or mobile networks, our patch antenna collection delivers superior signal strength, durability, and efficiency. As a leading manufacturer and supplier from China, we bring factory-direct quality to global markets.

Shop Patch Antennas Now– Fast shipping worldwide!

What is a Patch Antenna?

A patch antenna, also known as a microstrip patch antenna, is a low-profile antenna consisting of a metallic patch mounted over a ground plane. It excels in applications requiring compact size and directional performance, making it ideal for 5G, 4G, and 3G networks. Unlike bulky dipole antennas, patch designs radiate perpendicular to the patch surface, offering high gain (typically 5-10 dBi) in a flat form factor.

These antennas operate on principles of resonance, where the patch acts as a resonant cavity excited by a feed line. Common materials include FR4 substrates for cost-effectiveness or Rogers laminates for high-frequency precision. At AsiaLeren, our patch antennas support frequencies from 698 MHz to 6 GHz, covering sub-6 GHz 5G bands and legacy cellular standards.

Key Specs Across Our Range:

• Frequency: 698-960 MHz, 1710-2700 MHz, 3300-3800 MHz (5G NR)

• Gain: 5-9 dBi

• VSWR: ≤1.5

• Polarization: Linear or Circular

• Connector: SMA, N-Type, or Custom

Why Choose Patch Antennas from AsiaLeren?

In today's bandwidth-hungry world, patch antennas stand out for their versatility. They provide focused beams for point-to-point links, reducing interference in dense urban environments. Our China-based manufacturing ensures rigorous quality control, RoHS compliance, and competitive pricing – up to 30% below Western suppliers.

Advantages of AsiaLeren Patch Antennas:

• Compact Design: Thickness under 5mm, perfect for drones, vehicles, and embedded systems.

• Wide Bandwidth: Multi-band support for seamless 5G/4G/3G migration.

• Weatherproof Build: IP67-rated options for outdoor use.

• Customization: Tailored sizes, feeds (probe, inset, or aperture-coupled), and arrays.

As a direct manufacturer, we control every step – from PCB etching to RF testing – delivering antennas that meet MIL-STD standards. Bulk orders? Enjoy tiered discounts and OEM branding. View Main Category: 5G/4G/3G Antennas for our full wireless lineup.

Applications of Patch Antennas

Patch antennas power diverse industries, from telecommunications to defense. Their planar structure integrates easily into PCBs, enabling miniaturization without sacrificing performance.

• 5G Infrastructure: Beamforming arrays for small cells and massive MIMO.

• IoT and Smart Cities: Gateways, sensors, and asset trackers.

• Automotive: V2X communication and telematics.

• Drones/UAVs: Lightweight gimbals for video transmission.

• Satellite Comms: LEO terminals with circular polarization.

For example, our 5.8 GHz patch antenna boosts drone FPV range by 40%, while 2.4/5 GHz dual-band models suit WiFi-6 routers. Engineers love their simulation-friendly design – model in HFSS or CST for precise impedance matching.

Featured Patch Antenna Products

Browse our top patch antenna models, all in stock for immediate dispatch.

1. AL-PA698-2700 (Tri-Band Patch Antenna)

• Bands: 698-960 / 1710-2700 MHz

• Gain: 7 dBi

• Size: 120x120x1.6mm

2. AL-PA5G-3.5 (Sub-6 5G Patch)

• Frequency: 3300-3800 MHz

• Gain: 8.5 dBi

• IP67, SMA Connector

3. AL-PA-Circ (Circular Polarized Patch Array)

• Dual linear feeds for RHCP/LHCP

• Gain: 9 dBi

• Ideal for GPS/5G Satcom

Patch Antenna Technology Deep Dive

Patch antennas derive from microstrip theory, first theorized by Deschamps in 1953. The basic rectangular patch resonates when its length

Performance Metrics:

Solder-ready with gold-plated edges for corrosion resistance.

Why AsiaLeren? Your China-Based Patch Antenna Partner

With 10+ years in RF manufacturing, AsiaLeren supplies patch antennas to telecom giants and startups alike. Our ISO 9001-certified factory in China produces 50,000+ units monthly, ensuring scalability.

Ready to Upgrade Your Network?

Shop All Patch Antennas| Explore 5G/4G/3G Antennas Elevate your projects with AsiaLeren patch antennas – precision-engineered in China for global performance.
