GL174862
GLOBAL
50PC
Accepted
1000PC/Day
| Quantity: | |
|---|---|
| PDF Export | |
Item | 3-Element Antenna |
PN | GL174862 |
Frequency Range | 174−230/470−862 (MHz) |
Input Impedance | 75(Ω) |
Half-power Beamwidth | H 60±5∘ / E 66±5∘ |
Voltage Standing Wave Ratio (VSWR) | ≤2.0(665) |
Gain | 28 (dBi) |
Maximum Input Power | 50 (W) |
Noise Figure | ≤1.5 dB |
Power Supply Voltage | DC 5 V |
Current | ≤30 mA |
Front-to-back Ratio | ≥15 dB |
Polarization Type | Vertical or Horizontal |
Connector Model | F-type female |
Lightning Protection | DC Grounding |
Operating Temperature | -40℃~﹢65℃ |
Weight | 0.12 (kg) |
Antenna Dimensions | 185×170 (mm) |
Radiating Elements | 3 |
Item | 3-Element Antenna |
PN | GL174862 |
Frequency Range | 174−230/470−862 (MHz) |
Input Impedance | 75(Ω) |
Half-power Beamwidth | H 60±5∘ / E 66±5∘ |
Voltage Standing Wave Ratio (VSWR) | ≤2.0(665) |
Gain | 28 (dBi) |
Maximum Input Power | 50 (W) |
Noise Figure | ≤1.5 dB |
Power Supply Voltage | DC 5 V |
Current | ≤30 mA |
Front-to-back Ratio | ≥15 dB |
Polarization Type | Vertical or Horizontal |
Connector Model | F-type female |
Lightning Protection | DC Grounding |
Operating Temperature | -40℃~﹢65℃ |
Weight | 0.12 (kg) |
Antenna Dimensions | 185×170 (mm) |
Radiating Elements | 3 |
