GL-DYT014
asialeren
8517710000
50pcs
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Frequency Range (MHz) | 470-862 |
Bandwidth (MHz) | 70 |
Input Impedence (Ω) | 75 |
V.S.W.R | ≤1.5 |
Gain (dBi) | 5-7 |
Polarization | Vertical |
Power Capacity (w) | 50 |
Mechanical Specifications | |
Cable Length-m | 3m or Customizable |
Connect Type | F/USB |
Working Temp(℃) | -40~85 |
Radome Color | Black |
Dimensions-mm | Φ59.5*126 |
Product Introduction
Compact & Space-Efficient Design
With dimensions of Φ59.5×126 mm, this antenna offers a low-profile and unobtrusive design, making it ideal for both indoor and outdoor installations where space is limited.
Stable Signal with Wide Frequency Coverage
Operating across 470–862 MHz, the antenna ensures access to a broad range of free digital TV channels, delivering reliable HD quality without subscription fees.
Enhanced Reception with Optimized Gain
Featuring a gain of 5–7 dBi and vertical polarization, it effectively captures TV signals while minimizing interference, providing a clear and consistent viewing experience.
Flexible Installation & Custom Cable Options
The antenna comes with a standard 3m cable (customizable upon request) and supports F/USB connectivity, allowing easy integration with various TV setups and locations.
Durable All-Weather Construction
Built to perform in temperatures from -40°C to 85°C, this antenna is suitable for diverse environments—whether mounted indoors, outdoors, or in semi-protected areas.
Application Scenarios
City apartments and small homes: Compact and space-saving, easily placed on a windowsill or next to a TV cabinet, receiving local HD channels.
Dormitory or rental spaces: Plug and play, no drilling required, suitable for temporary living or space-constrained scenarios.
Outdoor or semi-outdoor use: Such as on balconies, in garages, or under awnings, its wide-temperature design ensures stable operation in various climates.
Vehicle or mobile scenarios: Suitable for use in RVs, travel, or temporary events, paired with a portable TV or monitor.
FAQ
Q: How many channels can I receive with the GL-DYT014 antenna?
A: The number of channels depends on your location and signal environment. Placing the antenna near a window or in an elevated position typically improves channel availability.
Q: Is the antenna easy to install?
A: Yes. It supports plug-and-play setup via F or USB connection. Simply connect it to your TV, place the antenna in an optimal location, and scan for channels.
Q: Can the cable length be customized?
A: Yes. The standard cable is 3 meters, but we offer customizable lengths to suit your installation needs.
Q: Does this antenna work in rural or low-signal areas?
A: With 5–7 dBi gain, it performs well in low to medium signal areas. For very weak signals, we recommend placing it as high as possible and avoiding obstructions.
Q: Is the antenna suitable for outdoor mounting?
A: Yes. Its operating temperature range of -40°C to 85°C makes it durable enough for most outdoor conditions, though we advise avoiding direct heavy rain exposure.
Q: What types of TVs are compatible?
A: It is compatible with most HDTVs and set-top boxes that have an F-type or USB input.
Q: What does "vertical polarization" mean for reception?
A: Vertical polarization helps reduce signal interference and aligns with the broadcast orientation of many TV stations, improving overall signal clarity.
