GL601
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
Product | 3G Screw antenna | |
P/N | GL-DY601 | |
Item | Specifications | |
GSM Antenna | Frequency Range | 824~960MHz/1710~2170MHz |
V.S.W.R | ＜2.0 | |
Polarization | Linear | |
Gain | 2.0dBi | |
Impedance | 50Ω | |
Mechanical | Cable | RG174 |
Connector | SMA/MCX/FAKRA or others | |
Material | Radome:ABS/Base:Cast Aluminum | |
Mounting Method | Screw | |
Environmental | Operating Temperature | -40℃~+85℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP67 (exclude cable outlet) | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
| Difference index between product numbers (P/N) | |||
| Index/(P/N) | GL-DY601 | GL-DY003 | GL-DY009 |
| Frequency range-mhz | 824-960MHz/1710-2170MHz | 698-960/1710-2690 | 700-3800 |
| Cable type and length | RG174 | RG174,2.5m | LMR195,3M |
Dual-Band GSM/3G Coverage – Supports 824-960MHz and 1710-2170MHz, ideal for 2G/3G networks and IoT applications.
Industrial-Grade Durability – IP67-rated housing (excluding cable outlet) with cast aluminum base and ABS radome for extreme conditions.
High-Performance Signal – 2.0dBi gain with VSWR <2.0 ensures efficient signal transmission.
Secure Screw Mounting – Robust screw fixation for stable installation on vehicles, machinery, or outdoor structures.
Wide Temperature Range – Operates in -40°C to +85℃ and 95% humidity, suitable for harsh environments.
Industrial IoT (IIoT) – Connects sensors and controllers in factories, oil rigs, and mining equipment.
Fleet & Vehicle Telematics – GPS tracking and communication for trucks, buses, and heavy machinery.
Marine & Offshore Systems – Resists saltwater corrosion for boat communication and navigation devices.
Remote Monitoring – Weatherproof solution for agricultural sensors and environmental stations.
Base Station Equipment – Reliable backup for 3G small cells and repeaters in rural areas.
Q:What frequency bands does GL-DY601 support?
A:824-960MHz (GSM/2G) and 1710-2170MHz (3G), covering most global networks.
Q:Is this antenna waterproof?
A:Yes, IP67-rated (excluding cable outlet) for dust/water resistance.
Q:What is the antenna’s gain?
A:2.0dBi, optimized for mid-range industrial communication.
Q:What connectors are available?
A:Standard SMA, MCX, or FAKRA (custom options upon request).
Q:Can it handle vibrations?
A:Yes, tested for 10-55Hz vibrations (1.5mm amplitude for 2 hours).
Q:Is it suitable for Arctic/desert use?
A:Yes, operates in -40°C to +85℃.
Q:Does it meet environmental standards?
A:Yes, ROHS compliant.
Q:What cable is included?
RG174 cable (length not specified; custom lengths available).
