GL-DY702
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Item | Specifications | |
DAB Antenna&Amplifier | Frequency Range | 174~237MHz/1452~1492MHz |
Wave Band | DAB BⅢ/L-Band | |
Polarization | Linear | |
Impedance | 50Ω | |
Gain | 10±2dB | |
Supply Voltage | 12V DC | |
Current Consumption | 40mA | |
FM/AM Antenna&Amplifier | Frequency Range | 520~1629KHz/76~108MHz |
Wave Band | AM/FM | |
Polarization | Linear | |
Impedance | AM＜90 pF FM:75~150 Ω | |
Gain | AM:6dB FM:7dB | |
Supply Voltage | 12V DC | |
Current Consumption | 60mA | |
Mechanical | Cable | RG174 |
PCB | FR4 | |
Connector | FME+M10×0.75+6.3 DIN 46340 | |
Mounting Method | Screw | |
Environmental | Operating Temperature | -40℃~+85℃ |
Relative Humidity | Up to 95% | |
Ingress Protection | IP65~IP66 (exclude cable outlet) | |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
Product Introduction
Dual-Band Signal Coverage
Supports DAB (174–237MHz / 1452–1492MHz) and AM/FM (520–1629KHz / 76–108MHz) bands, ensuring seamless radio and digital audio broadcasting reception.
High Durability for Harsh Environments
IP65-IP66 protection (excluding cable outlet) and -40℃ to +85℃ operating range, ideal for automotive, marine, and industrial use.
Plug-and-Play Installation
Includes screw-mount design and pre-assembled RG174 cable with FME/M10 connector, reducing setup time for vehicles or equipment.
Stable Signal Amplification
10dB gain for DAB and 6-7dB gain for AM/FM, enhancing weak signal reception in remote areas or during mobile operations.
Compliance & Safety
ROHS-certified and vibration-tested (10–55Hz for 2 hours), meeting EU/US environmental and industrial safety standards.
Automotive: Install in cars, trucks, or RVs for uninterrupted DAB+/FM radio during long-distance travel.
Marine: Waterproof design suits boats and ships for reliable AM/FM reception in humid conditions.
Industrial Machinery: Withstands vibrations in construction vehicles, agricultural equipment, or mining rigs.
Public Transport: Ensures stable radio signals for buses, trains, or emergency service vehicles.
Q:Is this antenna compatible with all DAB+ radios?
A:Yes. It works with any DAB+/FM/AM receiver using a standard FME/M10 connector.
Q:Can it be installed outdoors permanently?
A:Yes. IP65-IP66 rating protects against dust and water jets, but ensure the cable outlet is sealed.
Q:Does it require an external power supply?
A:Yes. It operates on 12V DC (40mA for DAB, 60mA for FM/AM).
Q:Is the antenna suitable for high-vibration environments?
A:Absolutely. Tested under 10–55Hz vibration for 2 hours, ideal for heavy machinery.
Q:Does it comply with EU/US regulations?
A:Yes. ROHS certification ensures compliance with environmental standards.
Q:What is the warranty period?
A:Contact the supplier (Global East Asia Technology) for warranty details.
