EnglishEnglish
GLU5FG3W
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range (MHz) | 480-580 |
Bandwidth (MHz) | 40 |
Horizontal Half-power Beamwidth (°) | 360 |
Vertical Half-power Beamwidth (°) | 56 |
Gain (dBi) | 3.5 |
Polarization | Vertical |
VSWR | ≤2.0 |
Average Power, Maximum (W) | 100 |
Impedance (Ω) | 50 |
Mechanical Specifications | |
Length (cm) | 60 |
Net Weight (kg) | 0.9 (installation kit included) |
Radome Material | Fiberglass |
Radome Color | White |
Connector | N Female |
Environmental Specifications | |
Application | Outdoor |
Operating Temperature (℃) | -40 to +70 (-40 to 158℉) |
Humidity (%) | 5 to 95 |
Survival Wind Velocity (km/h) | 200 |
Mounting Specifications | |
MOUNTING BRACKETS ARE INCLUDED UNLESS OTHERWISE SPECIFIED | |
Mounting Mast Diameter (mm) | Φ 40 to 70 |
Product Introduction
Application scenarios
Industrial Automation: Ensures stable communication for machinery and sensors in factories.
Agricultural Monitoring: Reliable connectivity for weather stations and IoT devices in remote fields.
Public Safety Systems: Supports emergency communication networks in urban/rural areas.
Telecom Infrastructure: Enhances signal coverage for base stations and repeaters.
FAQ
Q:What mast size does this antenna support?
A:It fits masts with diameters between 40-70mm.
Q:Is the antenna waterproof?
A:Yes, it’s designed for outdoor use with a fiberglass radome and humidity resistance (5-95%).
Q:Can it handle high winds?
A:Yes, it survives wind speeds up to 200 km/h.
Q:What devices is this antenna compatible with?
A:Compatible with any 50Ω system using an N-Female connector (e.g., radios, transceivers).
Q:Does it include mounting hardware?
A:Yes, mounting brackets are included.
Q:What’s the vertical beamwidth?
A:56°, optimized for broad vertical coverage.
Q:Is the VSWR adjustable?
A:, but it’s factory-tuned to ≤2.0 for minimal signal loss.
Q:How long is the antenna?
A:60cm, balancing performance and compactness.
