GL400V-6
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range- MHz | 380-450MHz |
VSWR | ≤2.0 |
Gain- dBi | 6 |
Horizontal beam width | 360° |
Vertical beam width | 30° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power- W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N female |
Connector place | Bottom |
Dimensions- mm | Ф32×1250 |
Antenna weight- kg | 1.5 |
Radome material | Fiberglass |
Radome color | white |
Operating temperature | -40°c～60°c |
Rated Wind Velocity- m/s | 60 |
Mounting hardware- mm | ￠35～￠60 |
Product Introduction
1. Broadband and Efficient Coverage: Operating in a frequency range of 380-450MHz, with 6dBi high gain and a 360° horizontal beamwidth, it provides all-around signal coverage, ensuring stable communication over a wide area.
2. High Power Capacity and Durable Design: Supporting a maximum input power of 100W, it utilizes a high-quality fiberglass antenna cover, withstands wind speeds of up to 60m/s, and operates stably in a wide operating temperature range of -40°C to 60°C, making it suitable for harsh outdoor environments.
3. Reliable Lightning Protection and Signal Stability: Equipped with DC grounding lightning protection, it reduces the risk of lightning strikes. With a VSWR of ≤2.0 and low signal return loss, it ensures efficient and stable signal transmission.
4. Convenient Installation and Compatibility: Equipped with an N-type female connector on the bottom and compatible with mounting hardware ranging from ￠35 to ￠60 mm, it can be easily installed on various brackets and is suitable for base stations, outdoor communication equipment, and other applications.
5. Environmentally friendly and long-lasting durability: The fiberglass material is corrosion-resistant and aging-resistant. The white appearance is both practical and beautiful, and meets the durability requirements of long-term outdoor use.
P/N | GL400V-6 | GL420V-8 | GLF400A |
Gain | 6.0 | 8.0 | 11.0 |
V.S.W.R. | 2.0 | 2.0 | 1.5 |
Application Scenario
1.Lightweight and Corrosion Resistance
2.Use in Marine and Coastal Environments
3.Integration in 5G and IoT Networks
4.Antenna Radomes and Covers
5.Durability in Extreme Weather Conditions
FAQ
Q: What frequency range does the GL400V-6 cover?
A: It covers the 380-450MHz frequency range.
Q: What is the gain of this omnidirectional antenna?
A: The gain is 6dBi.
Q: What is the maximum input power it can handle?
A: It can handle a maximum input power of 100W.
Q: What is the polarization type of the GL400V-6?
A: It uses vertical polarization.
Q: What are the dimensions of the antenna?
A: It measures Φ32 x 1250mm.
Q: What type of connector does it use?
A: It uses an N-type female connector located on the bottom.
