High Quality N female connector 430MHz 6dBi Omni Fiberglass Antenna GL430V-6

Differences between similar products

Product Introduction

① Hundred-Watt High-Power Handling

100W maximum input power (10 times the industry average), ceramic insulator + copper alloy oscillator, supports continuous high-power radio transmission

② Military-Grade Structural Protection

Fiberglass radome (φ32×1250mm) certified for 60m/s wind speeds (level 17 typhoon), -40°C to 60°C weatherproof operation

③ Precise Beam Control

360° omnidirectional coverage + 30° vertical beam angle reduces ground reflection interference and improves point-to-multipoint communication efficiency

④ Professional Lightning Protection

DC Grounding (DC Ground) lightning protection structure prevents damage to equipment caused by lightning-induced current (requires use with a grounding wire)

⑤ Convenient project deployment

Equipped with a standard N-type female connector, compatible with φ35-560mm diameter pipe brackets. A lightweight 1.5kg design reduces tower load.

Application Scenarios

Emergency Communication Base Station: 100W power supports wide-area communications for command vehicles in disaster areas.

Oil Pipeline Monitoring System: 430MHz offers barrier-free coverage in complex terrain.

Port Ship Dispatch: 360° omnidirectional communication ensures dock operations.

Forest Fire Prevention Relay: Fiberglass reinforced plastic offers high-temperature resistance (60°C extreme environment).

Mine Intercom System: DC grounding and lightning protection for open-pit mines.

FAQ

Q: What communication protocols are covered in the 430-440MHz band?

A: Supports professional digital intercom systems such as DMR/dPMR/TETRA, as well as analog FM communications.

Q: How is lightning protection grounding implemented?

A: Grounding is achieved through the N-type connector housing (user-provided 6mm² grounding wire with a ground resistance of <5Ω is required).

Q: Can it be used for amateur radio?

A: It is compatible with the 430MHz amateur band (subject to local compliance), but is designed for industrial, non-amateur use.

Q: Will the fiberglass cover age and yellow?

A: The UV protective coating guarantees 5 years of non-yellowing (verified by accelerated testing at 60°C/95% humidity).

Q: What are the advantages of a 30° vertical beam angle?

A: It compresses the vertical radiation range and increases horizontal signal density (+2dB gain compared to 45° products).

Q: Can other connectors be customized?

A: Standard N-type female connector, supports custom TNC/BNC connectors.
