GL120DP05
Asialeren
8517710000
50pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
P/N | GL120DP05 |
Freq-MHz | 150～400 |
Band Width-MHz | 20 |
Gain -dBi | 5 |
Beam Width-° | E:65 H:120 |
F/B Ratio-dB | ≥15 |
V.S.W.R | ≤2.0 |
Impedance-Ω | 50 |
Polarization | Vertical |
Isolation－dB | -- |
Max Power-W | 100 |
Lighting Protection | DC Ground |
Connector | N female |
Dimensions-mm | 600*280×125 |
Weight-Kg | 11 |
Pole Diameter-mm | ф40-90 |
Product Introduction
1. Ultra-wide Coverage Angle, Multi-purpose Tower: A wide beamwidth design with 120° horizontal and 65° vertical coverage allows a single antenna to cover a wide area, reducing the number of base station antennas and construction costs.
2. Dual Polarization Technology, More Stable Signal: Utilizing a dual polarization design, it effectively suppresses signal interference, improves communication quality, and is suitable for complex environments with multipath propagation.
3. Strong Corrosion Resistance, Long-Term Outdoor Use: The shell and structure have excellent corrosion resistance, making it suitable for highly corrosive environments such as coastal areas and industrial zones, extending its service life.
4. Integrated N-type Female Connector, Easy Installation: Standard N-K type connector, reliable interface, suitable for high-frequency signal transmission, and easier installation and maintenance.
5. Adjustable Bracket Design, Flexible Adaptability: Equipped with an adjustable mounting bracket, supporting pole diameters from φ40-90mm, adapting to various installation scenarios and angle requirements.
Application Scenarios
CDMA450 Rural Communication System
Village Connectivity Project Wireless Coverage Project
Signal Relay and Extension in Remote Areas
Dedicated Communication Networks for Mining Areas, Farms, and Mountainous Areas
Emergency Communication Vehicles and Mobile Base Station Antenna Deployment
FAQ
Q: What is the coverage angle of this antenna?
A: It has a 120° coverage in the horizontal plane and a 65° coverage in the vertical plane.
Q: Can it be used for CDMA450 systems?
A: Yes, it is specifically designed for CDMA450 and similar rural communication systems.
Q: What connector does it use?
A: It comes with an N-female connector.
Q: Is it suitable for outdoor use?
A: Yes, it features anti-corrosion treatment and DC grounding for lightning protection.
Q: What is the maximum power handling?
A: It can handle up to 100W of power.
Q: What is the weight of the antenna?
A: It weighs approximately 11 kg.
