GL-CV0802
GLOBAL
8517710000
10pc
Accepted
1000PC/Day
| Availability: | |
|---|---|
| Quantity: | |
| PDF Export | |
Frequency Range | 698-960/1710-2700/3300-3800/4800-5000MHz |
VSWR | 2.5 |
Impedance | 50 Ω |
Gain | 4-8dBi |
Polarization | Vertical or Horizontal |
Beam Width H(half-power) | 90/75/50/40° |
Beam Width V(half-power) | 65/50/40/35° |
Front to Back Ratio | ≥20dB |
Lightning Protection | DC Ground |
Max.Power | 100w |
Connector | SMA-male |
Dimension | 210x180x45mm |
Weight | 0.45Kg |
Radome Material | Protected ABS |
Cable | 2000mm |
Working Temperature | -40~60℃ |
Diameter of installation pole | Φ30-Φ53mm |

Frequency Range | 698-960/1710-2700/3300-3800/4800-5000MHz |
VSWR | 2.5 |
Impedance | 50 Ω |
Gain | 4-8dBi |
Polarization | Vertical or Horizontal |
Beam Width H(half-power) | 90/75/50/40° |
Beam Width V(half-power) | 65/50/40/35° |
Front to Back Ratio | ≥20dB |
Lightning Protection | DC Ground |
Max.Power | 100w |
Connector | SMA-male |
Dimension | 210x180x45mm |
Weight | 0.45Kg |
Radome Material | Protected ABS |
Cable | 2000mm |
Working Temperature | -40~60℃ |
Diameter of installation pole | Φ30-Φ53mm |
