GL-DY7027S7
Asialeren
8517710000
50pc
accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |||
Frequency Range-MHz | 698-960 | 1710-2700 | |
Polarization | ±45° | ||
VSWR | ≤2.0 | ≤1.5 | |
Gain-dBi | 6 | 8 | |
Horizontal beam width | 90°- 80° | 80°- 70° | |
Verticalbeam width | 80°- 70° | 65°- 60° | |
Front-to-back ratio | ≥10dB | ≥13dB | |
Isolation between ports-dB | ≥23 | ||
Intermodulation IM3(2x33dBm)-dBc | ≤-140 | ||
Input Impedance-Ω | 50 | ||
Maximum input power-W | 50 | ||
Lightning protection | DC Ground | ||
Mechanical Specifications | |||
Input connector type | 2×N-K | ||
Installation | Mounting on the wall | ||
Dimensions-mm | 308×190×80 | ||
Antenna weight-KGS | 0.88 | ||
Radiating Element Material | AI | ||
Radome material | ABS | ||
Radome color | White | ||
Operating temperature | -40°C to +65 °C | ||
Product Introduction
Dual-Band Coverage: Operates across 698-960MHz and 1710-2700MHz, ideal for multi-standard communication systems.
High Signal Gain: Delivers 6dBi (low band) and 8dBi (high band) for extended coverage in indoor environments.
Durable UV-Resistant Design: ABS radome protects against UV degradation, ensuring long-term reliability.
Compact & Lightweight: Measures 308×190×80mm and weighs only 0.88kg, simplifying installation in tight spaces.
Wide Operating Temperature: Functions reliably from -40°C to +65°C, suitable for harsh or variable climates.
Application scenarios
Indoor distributed antenna systems (DAS) in offices, hospitals, or shopping malls.
Enhancing cellular and wireless coverage in large commercial buildings.
Signal reinforcement for IoT hubs and smart building infrastructure.
Temporary setups requiring lightweight, easy-to-mount antennas.
Industrial facilities needing stable communication in extreme temperatures.
FAQ
Q:What frequency bands does this antenna support?
A:It covers 698-960MHz (low band) and 1710-2700MHz (high band).
Q:Is this antenna suitable for outdoor use?
A:Designed for indoor use; the UV-resistant radome protects against sunlight but it is not waterproof.
Q:What connectors are included?
A:Dual N-K connectors for robust RF connectivity.
Q:What is the antenna gain?
A:6dBi for the low band and 8dBi for the high band.
Q:How is it installed?
A:Wall-mounted using brackets (hardware not included).
Q:What is the maximum input power?
A:50W per port, ensuring compatibility with standard transmitters.
Q:Does it require a ground connection?
A:Yes, it includes DC ground lightning protection.
Q:What materials are used for the radome?
A:High-quality ABS plastic for durability and UV resistance.
