GL-DY7040S4707
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range- MHz | 698-960MHz/1710-2700MHz/3400-4000 |
Polarization | ±45° |
VSWR | ≤1.8 |
Gain-dBi | 6/7/8 |
Horizontal beam width | 75°/70°/65° |
Vertical beam width | 70°/65°/60° |
Front-to-back ratio-dB | ≥20 |
Isolation between ports-dB | ≥15 |
Input Impedance-Ω | 50 |
Maximum input power-W | 50 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | 4×N-K |
Connector place | Bottom |
Dimensions-mm | 308×420×82 |
Antenna weight-KGS | 2.8 |
Radome material | UPVC |
Radome color | Gray |
Operating temperature | -40°C to + 65 °C |
Rated Wind Velocity-m/s | 60 |
Mounting hardware-mm | ￠35～￠75 |
Product Introduction
Tri-Band Wide Coverage
Supports 698-960MHz, 1710-2700MHz, and 3400-4000MHz – ideal for 2G/3G/4G/5G networks with seamless backward compatibility.
High-Power Handling
50W max input power per port with DC lightning protection, built for industrial cellular towers and harsh environments.
Optimized Signal Performance
6-8dBi gain with ±45° polarization and ≥15dB port isolation enhances MIMO efficiency and reduces interference.
Extreme Weather Resilience
UPVC radome withstands -40°C to +65°C temperatures and 60m/s wind speeds – perfect for exposed tower installations.
Engineered Mounting System
Compatible with Ø35-75mm poles and lightweight design (2.8kg) for quick deployment on telecom infrastructure.
Telecom Operators: Upgrading 4G/5G base stations with wideband coverage
Industrial IoT: Reliable connectivity for smart factories/remote sensors
Emergency Networks: Rapid deployment for disaster recovery communications
Rural Connectivity: Extending cellular coverage to low-signal areas
Private 5G Networks: Building dedicated enterprise communication systems
Q: What cellular bands does this support?
A: Covers 698-960MHz (B12/B13/B5), 1710-2700MHz (B2/B3/B7), and 3400-4000MHz (n78/n77 5G bands).
Q: How many ports does it have?
A: 4× N-K connectors (bottom-mounted) for MIMO configurations.
Q: Is this antenna 5G-ready?
A: Yes! The 3400-4000MHz band supports 5G NR deployments.
Q: What’s the wind resistance rating?
A: Rated for 60m/s winds (216 km/h) – suitable for hurricane-prone areas.
Q: Can it handle high-power transmitters?
A: Yes, 50W max input power per port with DC-ground lightning protection.
Q: What’s the beamwidth configuration?
A: Horizontal: 65°-75° / Vertical: 60°-70° (varies by band for focused coverage).
Q: Is mounting hardware included?
A: Designed for Ø35-75mm poles – hardware typically sold separately.
Q: Why choose UPVC radome?
A: UPVC provides UV resistance, corrosion protection, and signal transparency in extreme temps.
