GL-DY1922V6
Asialeren
8517710000
50pc
accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range- MHz | 1920-2170 |
VSWR | ≤2.0 |
Gain- dBi | 6 |
Horizontal beam width | 360° |
Vertical beam width | 25° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power- W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N-K |
Connector place | Bottom |
Dimensions- mm | Ф20×400 |
Antenna weight- kg | 0.5 |
Radome material | Fiberglass |
Radome color | gray |
Operating temperature | -40°c～60°c |
Rated Wind Velocity- m/s | 60 |
Mounting hardware- mm | ￠35～￠60 |
Differences between similar products
P/N | GL-DY1922V6 | GL430V-6 | GL6940V5 |
Frequency-Mhz | 1920-2170 | 430-440 | 698-960/1710-2700/3400-4000 |
Gain-dBi | 6 | 5/6 | 5 |
Antenna Dimension-mm | Ф20×400 | Ф32×1250 | Ф60*780 |
Product Introduction
●Versatile Applications:Designed for 3G systems and ideal for point-to-multipoint communication setups, ensuring reliable connectivity in various environments.
●Durable Design: Constructed with high-quality fiberglass radome, this antenna is built to withstand harsh weather conditions and provide long-lasting performance.
●All-Weather Operation: Capable of performing seamlessly in any weather, the GL-DY1922V6 ensures consistent signal strength.
●High Gain Efficiency:With a 6dBi gain, this 3G omni-directional fiberglass antenna enhances transmission and reception, making it an essential component for robust communication networks.
●Easy Installation: Equipped with an N-K connector, the bottom connector placement allows for straightforward installation and integration into your existing setup.
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: What frequency range does the Fiberglass Antenna GL-DY1922V support?
A: The Fiberglass Antenna GL-DY1922V supports a frequency range of 1920-2170MHz, making it ideal for 3G system applications. This broad range ensures enhanced connectivity and reliable performance in various communication setups.
Q: Is the antenna suitable for outdoor use?
A:Absolutely! The Fiberglass Antenna GL-DY1922V is designed for all-weather operation, thanks to its robust fiberglass radome construction. This antenna exhibits strong environmental adaptability, ensuring reliable performance even in challenging outdoor conditions.
Q: How does the omni-directional design benefit my installation?
A: The omni-directional design of the Fiberglass Antenna GL-DY1922V allows for point-to-multipoint applications, providing 360-degree coverage. This means you can achieve wider coverage without the need for multiple antennas, making your installation more efficient and effective.
Q: What is the gain of the Fiberglass Antenna GL-DY1922V?
A: The Fiberglass Antenna GL-DY1922V features a gain of 6dBi, which enhances signal strength and quality. This makes it an excellent choice for improving reception and transmission performance in 3G systems.
Q: What type of connector does this antenna use?
A:The Fiberglass Antenna GL-DY1922V is equipped with an N-K connector type at the bottom, ensuring compatibility with a wide range of equipment and facilitating easy installation.
Q: Can this antenna be used in various environments?
A:Yes, the Fiberglass Antenna GL-DY1922V is engineered to thrive in diverse environmental conditions, thanks to its high-quality fiberglass radome. Whether you're in a metropolitan area or a rural setting, this antenna is built to maintain performance.
Electrical Specifications | |
Frequency Range- MHz | 1920-2170 |
VSWR | ≤2.0 |
Gain- dBi | 6 |
Horizontal beam width | 360° |
Vertical beam width | 25° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power- W | 100 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N-K |
Connector place | Bottom |
Dimensions- mm | Ф20×400 |
Antenna weight- kg | 0.5 |
Radome material | Fiberglass |
Radome color | gray |
Operating temperature | -40°c～60°c |
Rated Wind Velocity- m/s | 60 |
Mounting hardware- mm | ￠35～￠60 |
Differences between similar products
P/N | GL-DY1922V6 | GL430V-6 | GL6940V5 |
Frequency-Mhz | 1920-2170 | 430-440 | 698-960/1710-2700/3400-4000 |
Gain-dBi | 6 | 5/6 | 5 |
Antenna Dimension-mm | Ф20×400 | Ф32×1250 | Ф60*780 |
Product Introduction
●Versatile Applications:Designed for 3G systems and ideal for point-to-multipoint communication setups, ensuring reliable connectivity in various environments.
●Durable Design: Constructed with high-quality fiberglass radome, this antenna is built to withstand harsh weather conditions and provide long-lasting performance.
●All-Weather Operation: Capable of performing seamlessly in any weather, the GL-DY1922V6 ensures consistent signal strength.
●High Gain Efficiency:With a 6dBi gain, this 3G omni-directional fiberglass antenna enhances transmission and reception, making it an essential component for robust communication networks.
●Easy Installation: Equipped with an N-K connector, the bottom connector placement allows for straightforward installation and integration into your existing setup.
FAQ
Q:Can I get one sample?
A:Yes, sample is available.
Q:What's the delivery time?
A:3-5 working days for the sample, 10-15 working days for quantity below 5K.
Q: What frequency range does the Fiberglass Antenna GL-DY1922V support?
A: The Fiberglass Antenna GL-DY1922V supports a frequency range of 1920-2170MHz, making it ideal for 3G system applications. This broad range ensures enhanced connectivity and reliable performance in various communication setups.
Q: Is the antenna suitable for outdoor use?
A:Absolutely! The Fiberglass Antenna GL-DY1922V is designed for all-weather operation, thanks to its robust fiberglass radome construction. This antenna exhibits strong environmental adaptability, ensuring reliable performance even in challenging outdoor conditions.
Q: How does the omni-directional design benefit my installation?
A: The omni-directional design of the Fiberglass Antenna GL-DY1922V allows for point-to-multipoint applications, providing 360-degree coverage. This means you can achieve wider coverage without the need for multiple antennas, making your installation more efficient and effective.
Q: What is the gain of the Fiberglass Antenna GL-DY1922V?
A: The Fiberglass Antenna GL-DY1922V features a gain of 6dBi, which enhances signal strength and quality. This makes it an excellent choice for improving reception and transmission performance in 3G systems.
Q: What type of connector does this antenna use?
A:The Fiberglass Antenna GL-DY1922V is equipped with an N-K connector type at the bottom, ensuring compatibility with a wide range of equipment and facilitating easy installation.
Q: Can this antenna be used in various environments?
A:Yes, the Fiberglass Antenna GL-DY1922V is engineered to thrive in diverse environmental conditions, thanks to its high-quality fiberglass radome. Whether you're in a metropolitan area or a rural setting, this antenna is built to maintain performance.
