Fakra H Pink Screw Mounting External GPS GNSS Active Antenna

Product Introduction

1.High Gain: 28±2dB LNA Gain for enhanced signal reception.

2.Low Noise Figure: Noise figure of <1.5 for clear signal processing.

3.IP67 Protection: Durable and resistant to harsh weather conditions, ensuring reliability.

4.Wide Temperature Range: Operates between -40°C to 85°C for versatile use.

5.Energy Efficient: 3-5V DC supply voltage and low current consumption (5-15mA).

Application Scenarios

●Fleet Management: Real-time tracking for trucks/taxis

●Agricultural Machinery: Precision farming equipment guidance

●Marine Navigation: Boat GPS systems in wet environments

●Drone Positioning: UAVs requiring dual-system accuracy

●Industrial IoT: Heavy machinery telemetry in extreme temps

●Emergency Response: Reliable location data in disasters

FAQ

Q: What systems does this antenna support?
A: Dual-band coverage for GPS (1575.42MHz) and Glonass (1601-1610MHz).

Q: Is this antenna waterproof?
A: Yes, IP67-rated (water immersion protection), excluding cable outlet.

Q: What power supply does it require?
A: 3.3V-5V DC with low 5-15mA current consumption.

Q: Why is 3dB axial ratio important?
A: Ensures circular polarization accuracy for reliable signal reception during device movement.

Q: Can it withstand vehicle vibrations?
A: Yes, tested at 10-55Hz/1.5mm amplitude for 2 hours.

Q: What’s the benefit of 28dB LNA gain?
A: Amplifies weak satellite signals for faster lock-ons in urban canyons/forests.

Q: Which connector types are available?
A: FAKRA C blue (automotive standard) or SMA male options.

Q: Is cable length customizable?
A: Uses standard RG174 cable; length can be customized upon request.
