GL607
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical specifications | |
Frequency (MHz) | 700-960MHz/1710-6000MHz |
V.S.W.R | 2.0 Max |
Peak Gain (dBi) | 6dBi |
Impendance (Ohm) | 50 Ohm Nominal |
Mechanical and environmental specifications | |
Polarisation | Linear |
Radiation Pattern | Omni-directional |
Connector | SMA Male |
Cable Type | 302 |
Dimensions (mm) | 122.5*45 |
Material | ASA |
Operating Temp | -40°C to 85°C |
Storage Temp/Humidity | 25±5°C / <70% |
Product Introduction
1. Wide Band Coverage
Supports dual frequency bands of 700–960MHz and 1710–6000MHz, suitable for multiple communication standards, including LTE, 4G, and select 5G bands.
2. High-Gain Omnidirectional Signal
6dBi high gain and an omnidirectional radiation pattern provide 360° uniform coverage, suitable for multi-device access environments.
3. High-Quality Construction and Interface
ASA material housing offers strong weather resistance; SMA male connector paired with 302 cable ensures easy installation and stable connection.
4. Wide Operating Temperature Range
Operating temperature range of -40°C to 85°C, suitable for extreme indoor and outdoor industrial environments.
5. Low Standing Wave Ratio and Standard Impedance
VSWR ≤ 2.0 and 50Ω impedance ensure efficient signal transmission with low reflection loss.
Application Scenarios
Indoor/Outdoor Cellular Signal Enhancement
IoT Device Communications (e.g., Smart Meters, Remote Monitoring)
Industrial Wireless Communication Systems (e.g., Factory Wireless Networks)
Fleet Management and In-Vehicle Communication Systems
Broadband Access Devices and Wireless Router Extensions
FAQ
Q: Does this antenna support 5G?
A: It supports some 5G frequency bands (1710–6000MHz). The specific frequency band configuration depends on the local 5G frequency band.
Q: Is the antenna waterproof?
A: The documentation does not clearly indicate the waterproof rating. We recommend using it indoors or with a protective cover for use in humid environments.
Q: Is a mounting bracket included?
A: The standard product does not include a mounting bracket; it is optional.
Q: What is the cable length?
A: The cable length is not specified in the documentation. Please contact customer service to confirm custom options.
Q: Can it be used for in-vehicle communication?
A: Yes. Its omnidirectional characteristics and wide operating temperature range make it ideal for mobile communication environments in vehicles.
Q: What is the antenna impedance?
A: Standard 50 ohms, suitable for most communication equipment.
