GL148
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
Frequency range（MHz） | 868 |
Gain（dBi） | 3 |
Polarization | Vertical |
Impedance (Ω) | 50 |
Max Power (W) | 50 |
VSWR | ≤2.0 |
Connector | IPEX |
Dimensions(mm) | 34x7x0.1 |
| install way | adhesive |
Cable | RG1.13/RG1.37 |
Temperature (℃) | -30~60 |
Humidity (%) | 5~95 |
Differences between similar antennas
P/N | GL148 | GL-DY020 | GL-DY024 |
Gain | 3 | 4 | 2 |
V.S.W.R. | 2.0 | 2.0 | 2.0 |
The 868 MHz built-in patch antenna works based on the transmission and reception of electromagnetic waves.
The patch antenna usually consists of a thin sheet of metal or conductive material, called a "patch," which is placed on a dielectric substrate. Dielectric substrates are usually materials with a high dielectric constant, such as ceramic or plastic, to reduce energy loss and improve the efficiency of the antenna. Patch antennas can be designed in different shapes and sizes to suit different frequency requirements.
Frequency range（MHz） | 868 |
Gain（dBi） | 3 |
Polarization | Vertical |
Impedance (Ω) | 50 |
Max Power (W) | 50 |
VSWR | ≤2.0 |
Connector | IPEX |
Dimensions(mm) | 34x7x0.1 |
| install way | adhesive |
Cable | RG1.13/RG1.37 |
Temperature (℃) | -30~60 |
Humidity (%) | 5~95 |
Differences between similar antennas
P/N | GL148 | GL-DY020 | GL-DY024 |
Gain | 3 | 4 | 2 |
V.S.W.R. | 2.0 | 2.0 | 2.0 |
The 868 MHz built-in patch antenna works based on the transmission and reception of electromagnetic waves.
The patch antenna usually consists of a thin sheet of metal or conductive material, called a "patch," which is placed on a dielectric substrate. Dielectric substrates are usually materials with a high dielectric constant, such as ceramic or plastic, to reduce energy loss and improve the efficiency of the antenna. Patch antennas can be designed in different shapes and sizes to suit different frequency requirements.
