GL-DY086
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
Frequency range（MHz） | 868 |
Gain（dBi） | 0 |
Polarization | Liner |
Impedance (Ω) | 50 |
Max Power (W) | 50 |
VSWR | ≤2.0 |
Differences between similar antennas
P/N | GL-DY086 | GL148 | GL129 |
Gain | 0 | 3.0 | 3.0 |
V.S.W.R. | 2.0 | 2.0 | 2.0 |
Connector | UFL |
Dimensions(mm) | 37x7x0.8 |
Cable | RG1.13/RG1.37 |
Temperature (℃) | -30~60 |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Humidity (%) | 5~95 |
The 868 MHz internal patch antenna is an antenna specially designed for wireless communication devices operating in the 868 MHz frequency band.
Applications：
1.Three-point patch antennas are ideal for compact, embedded systems where board space is limited. Their low-profile and surface-mount design allow seamless integration into PCB layouts without the need for bulky external antennas.
2.These antennas are often tuned for ISM bands such as 868 MHz or 915 MHz, which are widely used in low-power, long-range wireless communication.
3.Three-point patch antennas are typically manufactured as SMD (Surface-Mount Device) components using ceramic or PCB-based materials.
This antenna is often used in applications that require low power consumption and long-distance communication, especially in Europe and some other countries and regions. 868 MHz is part of the ISM (Industrial, Scientific and Medical) frequency band and is commonly used in wireless sensor networks, smart home systems, asset management, logistics tracking and other applications.
