1207MHZ High precision antenna

Vertex Gain

B3I≥2.0dBi  B2b≥4.5dBi

B1I≥2.0dBi  L≥3.0dBi  S≥5.0dBi

Elevation Gain (20°)

B3I≥-1.5dBi  B2b≥2.0dBi

B1I≥-0.5dBi  L≥-1.0dBi S≥-1dBi

B1I≥-2.5dBi；L≥-3dBi；S≥-3dBi

L≥-3.5dBi；S≥-4.0dBi

Polarization

B3I(1268.52±10.23) MHz RHCP

B2b(1207.14±10.23)) MHz RHCP

B1I(1561.098±2.046) MHz RHCP

L(1615.68±4.08))MHz LHCP

S(2491.75±4.08) MHz RHCP

LNA Gain

42±2dB

Impedance

50Ω

In-band Flatness

±2dB

Phase center

±2mm

Storage temperature

-55℃ to +85℃

Operating temperature

-40℃ to +70℃

Horizontal Coverage Angle

360°

VSWR

≤2.0

Mounting way

Strong Magnet

Humidity

95% Non-condensing

Dimensions

D185.00±0.3mmH47.70.00±1.0mm

Connector

TNC-KF(waterproof)

Weight

≤500g
