GL-DY439
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
4G Rubber Antenna | |
GL-DY439 | |
Electrical Index | |
Frequency-MHz | 700-2700 |
Gain- dBi | 5.0 |
VSWR | ＜2.5 |
Radiation | Omni |
Normal Impedance -Ω | 50 |
Polarization | Vertical |
Mechanical Index | |
Connector | BNC/TNC |
Antenna Dimension-mm | Φ10*72 |
Radome Material | ABS |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋60 |
Humidity-﹪ | 5～95 |
| Difference index between product numbers (P/N) | |||
| Index/(P/N) | GL-DY439 | GL-DY418 | GL-DY431 |
| Frequency range-mhz | 700-2700 | 824-960 | 698-960/1710-2700 |
| Gain-dBi | 5 | 3 | 5 |
| Antenna Dimension-mm | Φ10*72 | Ø12.5*110 | Ø26.5*220 |
Product Introduction
Dual-Band 4G Coverage (698-2700MHz)
Supports global 4G LTE bands, ensuring reliable connectivity for wireless networks and IoT applications.
Omnidirectional Radiation Pattern
Provides 360° signal coverage for consistent performance in outdoor and indoor environments.
Compact & Durable Design
Ø10x72mm ABS radome with rubber construction resists harsh weather, ideal for industrial and outdoor use.
Wide Temperature Tolerance (-40℃~60℃)
Operates reliably in extreme cold or heat, suitable for remote or exposed installations.
Low VSWR & High Efficiency
VSWR <2.5 minimizes signal loss, paired with 3dBi gain for stable data transmission.
Application scenarios
Outdoor 4G Access Points: Enhances signal strength for remote network deployments.
Industrial IoT Sensors: Compact size fits into machinery for real-time monitoring.
Security Cameras: Omnidirectional coverage ensures uninterrupted video streaming.
Fleet Tracking Systems: Durable design withstands vehicle vibrations and temperature changes.
Rural Cellular Boosters: Improves 4G connectivity in low-signal areas.
FAQ
Q:What frequency bands does this antenna support?
A:It covers 698-960MHz and 1710-2700MHz, compatible with most 4G LTE networks.
Q:Is this antenna waterproof?
A:The ABS radome and rubber housing provide weather resistance, suitable for outdoor use.
Q:What connector type is included?
A:SMA male connector for easy integration with routers/modems.
Q:Can it be used in extreme temperatures?
A:Yes, it operates from -40℃ to +60℃, ideal for harsh environments.
Q:Does it support 5G networks?
A:No, it is optimized for 4G LTE and IoT applications up to 2700MHz.
Q:What is the radiation pattern?
A:Omnidirectional, ensuring 360° coverage for uniform signal distribution.
Q:Is the antenna ROHS-compliant?
A:Yes, it meets ROHS environmental standards.
Q:How long is the antenna’s lifespan?
A:Built with durable ABS and rubber, it ensures long-term reliability under stress.
