UWB New Network Small size Fiberglass Omni Antenna

Differences between similar products

Product Introduction

1. Ideal Frequency Range: Specifically tailored for the 3500 - 4500MHz frequency band, it is well - suited for 5G new network systems and point - to - multipoint applications, ensuring seamless 5G communication.

2. Compact & Lightweight: With dimensions of Φ15x200mm and a weight of only 0.1kg, it is easy to install and deploy, even in space - constrained environments.

3. Wide Bandwidth: Offering a wide bandwidth, it can handle multiple data streams simultaneously, providing high - speed and efficient 5G data transmission.

4. Omni - directional Coverage: The 360° horizontal beamwidth provides all - around signal distribution, making it convenient for various 5G devices to connect from different directions.

5. Durable Build: Constructed with high - quality fiberglass radome, it can withstand different weather conditions, operating stably within a temperature range of - 40°C to 60°C and resisting a rated wind velocity of 60 m/s.

6. Lightning Protection: Equipped with DC ground lightning protection, it safeguards the antenna and connected devices from electrical surges caused by lightning, enhancing the overall system's reliability.

Application scenarios

• 5G Indoor Networks: Ideal for installing in office buildings, shopping malls, and residential complexes to provide comprehensive 5G coverage indoors, enabling high - speed internet access for multiple devices.

• Small - scale 5G Base Stations: Can be used in small - scale 5G base stations in urban areas or remote locations to expand 5G network coverage and support a moderate number of connected devices.

• 5G - enabled IoT Devices: In industrial IoT applications, such as smart factories and logistics centers, it can be integrated into 5G - enabled IoT devices to ensure reliable and high - speed communication between devices.

• Outdoor 5G Hotspots in Limited Spaces: For setting up outdoor 5G hotspots in small public areas like parks, cafes with outdoor seating, or small event venues, providing 5G connectivity to users in those areas.

• 5G - powered Mobile Devices: Can be used as an external antenna for 5G - enabled mobile devices (such as some specialized tablets or laptops) to enhance the signal reception and improve the overall 5G experience.

• 5G - based Smart City Sensors: In smart city projects, it can be connected to various sensors (e.g., environmental sensors, traffic sensors) to transmit data over 5G networks in a reliable and efficient manner.




FAQ

Q:What is the maximum input power the GL - DY3545V5 antenna can handle?
A:The maximum input power is 50W.

Q:Can it be installed outdoors?
Yes, it is designed for all - weather operation. Its fiberglass radome construction allows it to withstand different weather conditions, making it suitable for outdoor installation.

Q:How does the wide bandwidth benefit the user?
A:The wide bandwidth enables the antenna to support multiple 5G frequency channels, allowing for higher data throughput and better performance when handling multiple data streams from various devices simultaneously.

Q:Is the antenna compatible with all 5G devices?
A:It operates in the 3500 - 4500MHz frequency range. As long as the 5G device is designed to work within this frequency band, it should be compatible. However, it's always best to verify the device's specifications.

Q:What is the advantage of the vertical beamwidth of 33°?
A:The 33° vertical beamwidth helps to focus the signal in a specific vertical area. This can be beneficial for optimizing the signal distribution based on the installation height and the target area of coverage, especially in multi - floor buildings or when covering a certain vertical space.

Q:How do I install the antenna?
A:It comes with an N - J connector at the bottom. It can be installed using a suction cup or other mounting seats, depending on the installation environment. Refer to the installation instructions for detailed steps.

Q:Does the antenna come with a warranty?
A:Warranty details may vary. Please contact our sales team or check the product documentation for specific warranty information regarding the GL - DY3545V5 antenna.
