GLR915
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
The 915MHz rubber antenna is an essential component for wireless communication systems. With a length of 395mm, it provides optimal signal reception and transmission capabilities. The SMA male connector ensures a secure and reliable connection to the device. This antenna is designed to operate in the 915MHz frequency range, making it suitable for various applications such as remote control systems, telemetry, and wireless data transmission. Its rubber construction offers durability and flexibility, allowing it to withstand harsh environmental conditions. Whether used in industrial or consumer electronics, the 915MHz rubber antenna delivers excellent performance and enhances the overall wireless communication experience.
915 Rubber Antenna | |
GLR915-5 | |
Electrical Index | |
Frequency-MHz | 915 |
Gain -dBi | 5 |
VSWR | ＜2.0 |
Normal Impedance -Ω | 50 |
Polarization | Linear |
Mechanical Index | |
Connector | RP-SMA male |
Antenna Dimension-mm | Ø14*395 |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Differences between similar antennas
P/N | GLR915 | GL-DY433 | GL-DY436 |
Gain | 5.0 | 2.0 | 5.0 |
V.S.W.R. | 2.0 | 2.0 | 2.5 |
High Gain 5dbi Waterproof Rubber Duck 915MHz Antenna for Telemetry/Wireless Data Transmission
The 915MHz rubber antenna is an essential component for wireless communication systems. With a length of 395mm, it provides optimal signal reception and transmission capabilities. The SMA male connector ensures a secure and reliable connection to the device. This antenna is designed to operate in the 915MHz frequency range, making it suitable for various applications such as remote control systems, telemetry, and wireless data transmission. Its rubber construction offers durability and flexibility, allowing it to withstand harsh environmental conditions. Whether used in industrial or consumer electronics, the 915MHz rubber antenna delivers excellent performance and enhances the overall wireless communication experience.
915 Rubber Antenna | |
GLR915-5 | |
Electrical Index | |
Frequency-MHz | 915 |
Gain -dBi | 5 |
VSWR | ＜2.0 |
Normal Impedance -Ω | 50 |
Polarization | Linear |
Mechanical Index | |
Connector | RP-SMA male |
Antenna Dimension-mm | Ø14*395 |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Differences between similar antennas
P/N | GLR915 | GL-DY433 | GL-DY436 |
Gain | 5.0 | 2.0 | 5.0 |
V.S.W.R. | 2.0 | 2.0 | 2.5 |
High Gain 5dbi Waterproof Rubber Duck 915MHz Antenna for Telemetry/Wireless Data Transmission
