GLWB5G03
GLOBAL
8517629900
100pc
Accepted
1000PC/Day
| Quantity: | |
|---|---|
| PDF Export | |
Chip | QCA9563+QCA9886+QCA8334 |
Wireless Speed | 900Mbps |
Antenna Gain | 15dBi |
Flash + RAM | 16MB+64MB |
Wireless Protocol | 802.11 a/n/ac wave2 |
Wireless Frequency Band | 5GHz |
WAN Port | 1x1000Mbps |
LAN Port | 1x1000Mbps |
Power Supply | PoE 12V/DC 12V |
Protection Rating | IP65 |
Transmission Distance | 5km |
Long-Distance Transmission – Covers up to 5km with stable 900Mbps wireless speed, perfect for point-to-point connectivity.
High-Gain Directional Antenna – Built-in 15dBi antenna ensures focused signal strength and reduced interference.
Rugged IP65 Enclosure – Weatherproof design protects against rain, dust, and extreme temperatures for reliable outdoor use.
Gigabit Ethernet Ports – Dual 10/100/1000Mbps ports (WAN+LAN) deliver high-speed wired connections for cameras, access points, or switches.
Flexible Power Options – Supports both 12V DC and PoE (Power over Ethernet) for easy installation without extra cabling.
Surveillance Systems – Extend video feeds from remote IP cameras to a central monitoring station over several kilometers.
Campus/Enterprise Networking – Connect buildings across a large campus or office park with high-speed, reliable wireless links.
Temporary Event Connectivity – Quickly deploy network access for outdoor events, construction sites, or pop-up venues.
Rural Internet Access – Bridge the gap between a wired internet source and remote homes or farms lacking cable infrastructure.
Warehouse/Industrial Sites – Link separate facilities or equipment yards without laying fiber optic cables.
Q: What is the maximum transmission distance of the GLWB5G03?
A: Under ideal line-of-sight conditions, it can achieve stable transmission up to 5 kilometers.
Q: Does this wireless bridge support Power over Ethernet (PoE)?
A: Yes, it supports PoE (12V passive PoE) as well as DC 12V power input for flexible installation.
Q: Can I use it in rainy or dusty environments?
A: Absolutely. The device has an IP65 rating, meaning it is fully protected against dust and water jets.
Q: What wireless standards does it support?
A: It supports 802.11 a/n/ac (Wave 2) on the 5GHz band, ensuring compatibility with most modern devices.
Q: How do I configure the bridge for point-to-point connection?
A: Configuration is typically done via a web interface. You can set one unit as an Access Point (AP) and the other as a Station (Client) to establish a link.
Q: Does it come with mounting hardware?
A: Yes, the package includes a mounting kit for pole or wall installation.
Chip | QCA9563+QCA9886+QCA8334 |
Wireless Speed | 900Mbps |
Antenna Gain | 15dBi |
Flash + RAM | 16MB+64MB |
Wireless Protocol | 802.11 a/n/ac wave2 |
Wireless Frequency Band | 5GHz |
WAN Port | 1x1000Mbps |
LAN Port | 1x1000Mbps |
Power Supply | PoE 12V/DC 12V |
Protection Rating | IP65 |
Transmission Distance | 5km |
Long-Distance Transmission – Covers up to 5km with stable 900Mbps wireless speed, perfect for point-to-point connectivity.
High-Gain Directional Antenna – Built-in 15dBi antenna ensures focused signal strength and reduced interference.
Rugged IP65 Enclosure – Weatherproof design protects against rain, dust, and extreme temperatures for reliable outdoor use.
Gigabit Ethernet Ports – Dual 10/100/1000Mbps ports (WAN+LAN) deliver high-speed wired connections for cameras, access points, or switches.
Flexible Power Options – Supports both 12V DC and PoE (Power over Ethernet) for easy installation without extra cabling.
Surveillance Systems – Extend video feeds from remote IP cameras to a central monitoring station over several kilometers.
Campus/Enterprise Networking – Connect buildings across a large campus or office park with high-speed, reliable wireless links.
Temporary Event Connectivity – Quickly deploy network access for outdoor events, construction sites, or pop-up venues.
Rural Internet Access – Bridge the gap between a wired internet source and remote homes or farms lacking cable infrastructure.
Warehouse/Industrial Sites – Link separate facilities or equipment yards without laying fiber optic cables.
Q: What is the maximum transmission distance of the GLWB5G03?
A: Under ideal line-of-sight conditions, it can achieve stable transmission up to 5 kilometers.
Q: Does this wireless bridge support Power over Ethernet (PoE)?
A: Yes, it supports PoE (12V passive PoE) as well as DC 12V power input for flexible installation.
Q: Can I use it in rainy or dusty environments?
A: Absolutely. The device has an IP65 rating, meaning it is fully protected against dust and water jets.
Q: What wireless standards does it support?
A: It supports 802.11 a/n/ac (Wave 2) on the 5GHz band, ensuring compatibility with most modern devices.
Q: How do I configure the bridge for point-to-point connection?
A: Configuration is typically done via a web interface. You can set one unit as an Access Point (AP) and the other as a Station (Client) to establish a link.
Q: Does it come with mounting hardware?
A: Yes, the package includes a mounting kit for pole or wall installation.
