GL-DY001
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
GPSGlonass Antenna | |
GL-DY001 | |
Electrical Index | |
Frequency-MHz | 1575.42±1/1601-1610 |
VSWR | ＜1.5 |
Nominal Impedance-Ω | 50 |
Polarization | RHCP, |
Axial Ratio | 3dB(max) |
LNA Gain | 28±2dB |
Noise Figure | ＜1.5 |
Supply Voltage | 2.2-5V DC |
Current Consumption | 5-15mA |
Mechanical Index | |
Cable Length | RG174,5m |
Connector | Fakra C blue |
Antenna Dimension-mm | 49.4*39.3*14.9 |
Installation Way | Magnet or Adhesive |
Ingress Protection | IP65~IP67(exclude cable outlet) |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Product Introduction
Application scenarios
Drone Navigation: Enhances positioning accuracy for aerial surveying and delivery.
Marine Systems: Waterproof design for boats and offshore equipment tracking.
Fleet Tracking: Reliable GPS data for logistics and transportation management.
Precision Agriculture: Supports autonomous tractors and soil sensors.
Industrial IoT: Monitors assets in factories and warehouses.
FAQ
Q: What connectors does this antenna use?
A: FAKRA C blue connector (standard), with customization options available.
Q: Is it compatible with both GPS and Glonass?
A: Yes, dual-frequency support covers GPS L1 and Glonass L1 bands.
Q: What power supply is required?
A: Operates on 2.2-5V DC with low current consumption (5-15mA).
Q: Can it withstand heavy vibration?
A: Yes, tested under 10-55Hz vibration for 2 hours, suitable for vehicles and machinery.
Q: How is the antenna installed?
A: Use the built-in magnet or adhesive for quick mounting on metal surfaces.
Q: Is the cable waterproof?
A: The antenna body is IP67-rated, but the cable outlet requires additional protection in harsh environments.
Q: What’s the cable length?
A: 5m RG174 cable (standard), with options for custom lengths.
Q: Do you offer OEM/ODM services?
A: Yes, contact us for customized connectors, cable lengths, or branding.
