GL1038
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Frequency Range (MHz) | 87.5-862 |
Bandwidth (MHz) | 70 |
Input Impedence (Ω) | 75 |
V.S.W.R | ≤ 1.5 |
Gain (dBi) | 5-7 |
Polarization | Vertical |
Power Capacity (w) | 50 |
Mechanical Specifications | |
Cable Length-m | 3 |
Connect Type | USB/IEC |
Working Temp(℃) | -40~85 |
Radome Color | Black |
Dimensions-mm | Ø112*220 |
Product Introduction
Dual-Function Entertainment Solution
Covering 87.5-862 MHz, this unique antenna receives both HDTV signals and FM radio broadcasts, eliminating the need for separate antennas and providing complete audio-visual entertainment.
Optimized Vertical Polarization Design
Featuring vertical polarization, the antenna aligns with most broadcast signals to minimize interference and maximize reception clarity, especially in urban environments.
Space-Efficient Cylinder Design
With dimensions of Ø112×220 mm, the sleek cylindrical form factor fits discreetly in any room layout while providing stable 360° signal reception without requiring rotation.
Convenient USB Power Option
The USB/IEC connectivity allows flexible powering options—use your TV's USB port or any standard adapter for easy plug-and-play installation without extra cables.
Reliable All-Season Performance
Built to operate in extreme temperatures from -40°C to 85°C, this antenna ensures consistent performance year-round, whether placed indoors or in semi-protected outdoor areas.
Urban Apartments and Small Residences: The cylindrical design saves space, ideal for placement on TV cabinets or windowsills, providing HD TV and radio reception for users with limited space.
Music Lovers and Radio Listeners: Full FM radio coverage, suitable for users who enjoy listening to music, news, and talk shows through a sound system.
Second Entertainment Spaces: Provides TV signal and background music solutions for secondary spaces in the home, such as bedrooms, studies, and kitchens.
Student Dormitories and Rental Housing: Easy installation, no-drill design, suitable for temporary living environments, and easily portable during moves.
Commercial and Office Spaces: Restaurants, cafes, offices, and other commercial environments requiring background music and television programs.
Q: Can this antenna really receive FM radio stations?
A: Yes, with its 87.5-862 MHz frequency range, it captures both digital TV signals and FM radio broadcasts, providing two entertainment sources in one device.
Q: How many TV channels can I expect to receive?
A: The number varies by location, but the wide frequency coverage ensures maximum access to available digital channels in your area.
Q: Is the antenna difficult to install?
A: Not at all. Simply connect the IEC plug to your TV and the USB cable to your TV's USB port or a power adapter, then place the antenna in an optimal location.
Q: Does the cylindrical design require specific orientation?
A: No, its cylindrical form provides omni-directional reception, meaning it captures signals from all directions without needing to be pointed toward broadcast towers.
Q: Can I use this antenna outdoors?
A: While designed for indoor use, its wide temperature tolerance allows installation in covered outdoor areas like balconies, patios, or garages.
Q: What types of devices is it compatible with?
A: It works with most modern HDTVs, set-top boxes, and FM radios that have standard IEC antenna inputs and USB power capability.
Frequency Range (MHz) | 87.5-862 |
Bandwidth (MHz) | 70 |
Input Impedence (Ω) | 75 |
V.S.W.R | ≤ 1.5 |
Gain (dBi) | 5-7 |
Polarization | Vertical |
Power Capacity (w) | 50 |
Mechanical Specifications | |
Cable Length-m | 3 |
Connect Type | USB/IEC |
Working Temp(℃) | -40~85 |
Radome Color | Black |
Dimensions-mm | Ø112*220 |
Product Introduction
Dual-Function Entertainment Solution
Covering 87.5-862 MHz, this unique antenna receives both HDTV signals and FM radio broadcasts, eliminating the need for separate antennas and providing complete audio-visual entertainment.
Optimized Vertical Polarization Design
Featuring vertical polarization, the antenna aligns with most broadcast signals to minimize interference and maximize reception clarity, especially in urban environments.
Space-Efficient Cylinder Design
With dimensions of Ø112×220 mm, the sleek cylindrical form factor fits discreetly in any room layout while providing stable 360° signal reception without requiring rotation.
Convenient USB Power Option
The USB/IEC connectivity allows flexible powering options—use your TV's USB port or any standard adapter for easy plug-and-play installation without extra cables.
Reliable All-Season Performance
Built to operate in extreme temperatures from -40°C to 85°C, this antenna ensures consistent performance year-round, whether placed indoors or in semi-protected outdoor areas.
Urban Apartments and Small Residences: The cylindrical design saves space, ideal for placement on TV cabinets or windowsills, providing HD TV and radio reception for users with limited space.
Music Lovers and Radio Listeners: Full FM radio coverage, suitable for users who enjoy listening to music, news, and talk shows through a sound system.
Second Entertainment Spaces: Provides TV signal and background music solutions for secondary spaces in the home, such as bedrooms, studies, and kitchens.
Student Dormitories and Rental Housing: Easy installation, no-drill design, suitable for temporary living environments, and easily portable during moves.
Commercial and Office Spaces: Restaurants, cafes, offices, and other commercial environments requiring background music and television programs.
Q: Can this antenna really receive FM radio stations?
A: Yes, with its 87.5-862 MHz frequency range, it captures both digital TV signals and FM radio broadcasts, providing two entertainment sources in one device.
Q: How many TV channels can I expect to receive?
A: The number varies by location, but the wide frequency coverage ensures maximum access to available digital channels in your area.
Q: Is the antenna difficult to install?
A: Not at all. Simply connect the IEC plug to your TV and the USB cable to your TV's USB port or a power adapter, then place the antenna in an optimal location.
Q: Does the cylindrical design require specific orientation?
A: No, its cylindrical form provides omni-directional reception, meaning it captures signals from all directions without needing to be pointed toward broadcast towers.
Q: Can I use this antenna outdoors?
A: While designed for indoor use, its wide temperature tolerance allows installation in covered outdoor areas like balconies, patios, or garages.
Q: What types of devices is it compatible with?
A: It works with most modern HDTVs, set-top boxes, and FM radios that have standard IEC antenna inputs and USB power capability.
