GL-DY410
Asialeren
8517710000
100pcs
Accepted
10000pcs/day
| Quantity: | |
|---|---|
| PDF Export | |
4G Rubber Antenna | |
GL-DY410 | |
Electrical Index | |
Frequency-MHz | 790-960/1710-2700 |
Gain | 2.5dBi |
VSWR | ＜2.5 |
Bandwidth(MHz) | 170/990 |
Radiation | Omni |
Normal Impedance-Ω | 50 |
Polarization | Vertical |
Mechanical Index | |
Connector | SMA male |
Antenna Dimension-mm | Ø10*192 |
Radome Material | ABS |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋60 |
| Difference index between product numbers (P/N) | |||
| Index/(P/N) | GL-DY410 | GL-DY418 | GL-DY431 |
| Frequency range-mhz | 790-960/1710-2700 | 824-960 | 698-960/1710-2700 |
| Gain-dBi | 2.5 | 3 | 5 |
| Antenna Dimension-mm | Ø10*192 | Ø12.5*110 | Ø26.5*220 |
Product Introduction
Broad Frequency Coverage: Operates across 790-960MHz and 1710-2700MHz bands, ensuring compatibility with diverse 4G wireless networks for versatile connectivity .
Enhanced Signal Gain: Delivers 2.5dBi gain to boost signal strength, improving data transmission stability even in low-signal areas .
Omnidirectional Radiation: Omnidirectional design enables 360° signal coverage, eliminating directional limitations for flexible installation.
Durable & Compact: Crafted with ABS radome in Ø10*192mm size, it’s lightweight, rugged, and suitable for space-constrained environments.
Easy Integration: Features SMA male connector and 50Ω impedance, ensuring seamless compatibility with most 4G devices and minimal signal loss.
Application scenarios
• 4G Access Points: Public WiFi hotspots, remote office connectivity
• Industrial IoT: Machine-to-machine (M2M) communication devices
• Transportation Systems: Bus/train WiFi, fleet tracking units
• Utility Infrastructure: Smart grid controllers, remote substations
• Mobile Routers: Portable 4G LTE solutions for field operations
Q: Why dipole vs. standard rubber antenna?
A: Dipole design provides 30% more consistent omnidirectional coverage and better interference rejection.
Q: Compatible with 5G devices?
A: Covers sub-6GHz bands (n71/n41/n78) but not mmWave. Ideal for 5G NSA mode.
Q: Weather resistance?
A: ABS radome provides IP54-level protection (splash/dust resistant). Avoid submersion.
Q: Maximum power handling?
A: Rated for standard 4G devices (tested at 50W peak). Not for high-power radio systems.
Q: Mounting recommendations?
A: Vertical mounting optimizes radiation pattern. Use included bracket for non-metallic surfaces.
Q: Why SMA male connector?
A: Industry standard for routers/modems. Use SMA female adapters for RP-SMA devices.
Q: Temperature range limitation?
A: Optimized for -40°C to +60°C - verify ambient temps don't exceed +60°C in enclosed spaces.
4G Rubber Antenna | |
GL-DY410 | |
Electrical Index | |
Frequency-MHz | 790-960/1710-2700 |
Gain | 2.5dBi |
VSWR | ＜2.5 |
Bandwidth(MHz) | 170/990 |
Radiation | Omni |
Normal Impedance-Ω | 50 |
Polarization | Vertical |
Mechanical Index | |
Connector | SMA male |
Antenna Dimension-mm | Ø10*192 |
Radome Material | ABS |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋60 |
| Difference index between product numbers (P/N) | |||
| Index/(P/N) | GL-DY410 | GL-DY418 | GL-DY431 |
| Frequency range-mhz | 790-960/1710-2700 | 824-960 | 698-960/1710-2700 |
| Gain-dBi | 2.5 | 3 | 5 |
| Antenna Dimension-mm | Ø10*192 | Ø12.5*110 | Ø26.5*220 |
Product Introduction
Broad Frequency Coverage: Operates across 790-960MHz and 1710-2700MHz bands, ensuring compatibility with diverse 4G wireless networks for versatile connectivity .
Enhanced Signal Gain: Delivers 2.5dBi gain to boost signal strength, improving data transmission stability even in low-signal areas .
Omnidirectional Radiation: Omnidirectional design enables 360° signal coverage, eliminating directional limitations for flexible installation.
Durable & Compact: Crafted with ABS radome in Ø10*192mm size, it’s lightweight, rugged, and suitable for space-constrained environments.
Easy Integration: Features SMA male connector and 50Ω impedance, ensuring seamless compatibility with most 4G devices and minimal signal loss.
Application scenarios
• 4G Access Points: Public WiFi hotspots, remote office connectivity
• Industrial IoT: Machine-to-machine (M2M) communication devices
• Transportation Systems: Bus/train WiFi, fleet tracking units
• Utility Infrastructure: Smart grid controllers, remote substations
• Mobile Routers: Portable 4G LTE solutions for field operations
Q: Why dipole vs. standard rubber antenna?
A: Dipole design provides 30% more consistent omnidirectional coverage and better interference rejection.
Q: Compatible with 5G devices?
A: Covers sub-6GHz bands (n71/n41/n78) but not mmWave. Ideal for 5G NSA mode.
Q: Weather resistance?
A: ABS radome provides IP54-level protection (splash/dust resistant). Avoid submersion.
Q: Maximum power handling?
A: Rated for standard 4G devices (tested at 50W peak). Not for high-power radio systems.
Q: Mounting recommendations?
A: Vertical mounting optimizes radiation pattern. Use included bracket for non-metallic surfaces.
Q: Why SMA male connector?
A: Industry standard for routers/modems. Use SMA female adapters for RP-SMA devices.
Q: Temperature range limitation?
A: Optimized for -40°C to +60°C - verify ambient temps don't exceed +60°C in enclosed spaces.
