GLW58FG8Q10NM
Asialeren
8517710000
50pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |||
Frequency Range (MHz) | 5700-5850 | ||
Horizontal beam width(°) | 360 | ||
Vertical beam width (°) | 15 | ||
Gain (dBi) | 8 | ||
Polarization | Vertical | ||
VSWR | ≤2.0 | ||
Maximum input power (W) | 100 | ||
Impedance (Ω) | 50 | ||
Mechanical Specifications | |||
Dimensions (mm) | Φ20*300 | ||
Antenna weight (Kg) | 0.2 | ||
Radome material | fiberglass | ||
Radome color | grey | ||
Input connector type | N-K | ||
Environmental indicators | |||
Usage scenarios | Outdoor | ||
Operating temperature (℃) | -40 to +70 | ||
Humidity range (%) | 5 to 95 | ||
Maximum wind speed (km/h) | 200 | ||
Installing the Hardware | |||
Installation | Connector fixing | ||
Product Introduction
1. Professional 5.8GHz Band Optimization
Designed specifically for the 5700-5850MHz band, it's perfectly compatible with 5.8GHz WiFi and ISM band devices, providing a cleaner frequency environment.
2. High-Gain Omnidirectional Coverage
8dBi high gain combined with a 360° horizontal beamwidth delivers exceptional signal transmission and extended coverage.
3. Precision Vertical Beam Control
A narrow 15° vertical beamwidth provides a more focused signal, effectively reducing interference and increasing transmission distance and stability.
4. Industrial-Grade Protective Design
High-strength fiberglass casing is corrosion-resistant, UV-resistant, and IP-rated, making it suitable for harsh outdoor environments.
5. High-Power Stable Transmission
Supports a maximum input power of 100W, ensuring stable operation under high loads, making it suitable for professional applications.
Application Scenarios
5.8GHz WiFi base station and hotspot coverage
Long-distance point-to-point wireless transmission
UAV HD image and data transmission
Industrial wireless control systems (SCADA)
Remote monitoring and security systems
Intelligent transportation and connected vehicle systems
Outdoor wireless network deployment
Emergency rescue and temporary communication systems
FAQ
Q: What frequency bands does this antenna support?
A: Optimized for the 5700-5850MHz frequency band, it perfectly supports 5.8GHz WiFi and ISM band applications.
Q: What are the advantages of 8dBi high gain?
A: It provides longer transmission distance, stronger signal penetration, and more stable connection quality.
Q: Is the antenna waterproof? Is it suitable for outdoor use?
A: Yes, it features an industrial-grade fiberglass housing with excellent waterproof, dustproof, and weatherproof properties, designed for outdoor environments.
Q: What is the maximum supported power?
A: The maximum input power is 100W, meeting the needs of professional high-power applications.
Q: What are the dimensions and weight of the antenna?
A: The size is Φ20*300mm and the weight is only 0.2kg, which is light and easy to install and deploy.
