English
GLF9FG3B
Asialeren
8517710000
50pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |||
Frequency Range (MHz) | 890-950 | ||
Horizontal beam width(°) | 360 | ||
Vertical beam width (°) | 60 | ||
Gain (dBi) | 3 | ||
Polarization | Vertical | ||
VSWR | ≤2.0 | ||
Maximum input power (W) | 150 | ||
Impedance (Ω) | 50 | ||
Mechanical Specifications | |||
Dimensions (mm) | Φ20×300 | ||
Antenna weight (Kg) | 0.2 | ||
Radome material | fiberglass | ||
Radome color | grey | ||
Input connector type | N-K | ||
Environmental indicators | |||
Usage scenarios | Outdoor | ||
Operating temperature (℃) | -40 to +70 | ||
Humidity range (%) | 5 to 95 | ||
Maximum wind speed (km/h) | 200 | ||
Installing the Hardware | |||
Installation | Connector fixing | ||
Product Introduction
1. True Omnidirectional Coverage: A 360° horizontal beamwidth ensures signal reception and transmission without blind spots in the horizontal plane, providing a stable and reliable connection.
2. Rugged Outdoor Durability: Utilizing fiberglass radome, it offers excellent corrosion and UV resistance, and can withstand extreme temperatures ranging from -40°C to +70°C and 95% humidity.
3. High-Efficiency Signal Transmission: 3dBi gain combined with a VSWR (voltage standing wave ratio) of ≤2.0 ensures high signal transmission efficiency with minimal energy loss.
4. High Power Capacity: Supports a maximum input power of up to 150W, meeting the stringent requirements of professional high-power wireless communication systems.
5. Plug-and-Play Convenience: Standard N-K connectors and simple connector fixing ensure quick and easy integration into existing systems.
Application Scenarios
●Industrial IoT and Automation: Suitable for equipment data acquisition and monitoring systems on factory floors and production lines.
●Remote SCADA Systems: Suitable for remote monitoring and data transmission in the power, water, and oil and gas industries.
●Outdoor wireless network coverage: Provides communication coverage for complex outdoor areas such as farms, mining areas, and wind farms.
●Smart metering network: Connects remotely deployed smart water, electricity, and gas meters.
FAQ
Q: What is the operating frequency band of this antenna?
A: It is designed to operate specifically in the 890-950 MHz frequency band.
Q: Is this antenna suitable for permanent outdoor installation?
A: Absolutely. It is built for outdoor scenarios with a fiberglass radome, and can withstand temperatures from -40°C to +70°C and wind speeds up to 200 km/h.
Q: What type of connector does it use?
A: It comes with a standard N-K type (Female) connector for reliable connectivity.
Q: How much gain does this antenna provide?
A: This antenna offers a gain of 3 dBi.
Q: How is the beamwidth characterized?
A: It features a 360° horizontal beamwidth and a 60° vertical beamwidth for wide coverage.
Q: What are the physical dimensions and weight?
A: The antenna is 300mm in length with a 20mm diameter, and weighs only 0.2 kg, making it relatively lightweight.
