3.5G Magnet Antenna 241mm Height

Product introduction

1.High Gain & Low VSWR – 5dBi gain with VSWR <1.8 ensures strong, stable signal reception and transmission in the 3400-3600MHz band.

2.Durable Magnetic Mount – Strong magnetic base allows instant, tool-free installation on any metal surface, perfect for mobile or temporary setups.

3.Wide Temperature Tolerance – Operates reliably from -40°C to +85°C, suitable for extreme outdoor environments.

4.Compact & Lightweight – 241mm antenna length and only 180g weight, plus 2m RG174 low-loss cable with SMA male connector for easy integration.

5.Environmentally Friendly – Fully RoHS compliant, built with vibration resistance (10-55Hz, 1.5mm amplitude for 2 hours) for long-lasting performance.

Application Scenarios

In-vehicle 3.5G connectivity – Mount on car roofs or trunks for enhanced mobile broadband on the road.

Outdoor CPE and routers – Attach to metal cabinets or rooftop sheets to boost 3.5G signal strength.

IoT and M2M devices – Ideal for remote monitoring stations, vending machines, and industrial gateways requiring stable 3400-3600MHz links.

Temporary event networks – Quickly deploy on metal structures for pop-up shops, outdoor festivals, or emergency communication.

Marine and RV applications – Magnetic attachment on boats or recreational vehicles provides reliable 3.5G coverage in coastal or rural areas.FAQ

Q: Is this antenna compatible with 5G networks?

A: It is designed for 3.5G (3400-3600MHz). While some 5G bands overlap, please check your device’s frequency requirements.

Q: Can I install it on a non-metal surface?

A: The magnetic base requires a ferrous metal surface for secure attachment. For non-metal surfaces, use an adhesive metal plate (not included).

Q: Does it support both transmit and receive?

A: Yes, it is a passive antenna that works for both TX and RX within its frequency range.

Q: What is the connector type?

A: It comes with an SMA male connector and a 2-meter RG174 cable.

Q: Is the cable replaceable?

A: The cable is permanently attached. For different lengths, you can use an SMA extension cable (female to male).

Q: How weatherproof is it?

A: Rated for -40~+85°C and 5~95% humidity. The base is magnet-sealed; avoid submersion.
