English
GL006
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
2.4G WIFI Antenna | |
GL006 | |
Electrical Index | |
Frequency-MHz | 2400-2500 |
VSWR | ＜1.5 |
Normal Impedance-Ω | 50 |
Polarization | Liner |
| Gain | 3dBi |
Mechanical Index | |
Cable Length | RG174,3m |
Connector | customized |
Antenna Dimension-mm | 46*38.5*13.5 |
Installation Way | Magnet or Adhesive |
Ingress Protection | IP65~IP67(exclude cable outlet) |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋85 |
Humidity-﹪ | 5～95 |
Product Introduction
1. Flexible Installation, Secure Adhesion
The antenna offers both magnetic and adhesive mounting options. The strong magnetic base securely attaches to any metal surface (such as cabinets, vehicles, and equipment housings), while the 3M adhesive backing is suitable for non-metallic materials, allowing you to flexibly choose the right mounting method for your site, enabling quick installation.
2. Durable and Built to Last in Harsh Outdoor Environments
It features IP65-IP67 dust and water resistance (excluding the cable outlet), effectively protecting against rain and dust. With an operating temperature range of -40°C to +85°C and the ability to withstand continuous vibration, it is designed for reliable operation in outdoor and industrial environments.
3. Stable Performance, Optimized Signal Connection
Across the entire 2.4GHz band (2400-2500MHz), the voltage standing wave ratio (VSWR) is below 1.5, ensuring efficient signal transmission and minimizing energy reflections. The 3dBi gain enhances signal strength while maintaining wide coverage.
4. Plug-and-play, with wide compatibility.
The standard 3-meter RG174 flexible thin cable allows for flexible routing around devices. We offer custom connectors for perfect compatibility with various brands of routers, CPE, IoT gateways, and other devices, making it easy to replace or upgrade the original antenna.
5. Compact and environmentally friendly, meeting high standards.
The antenna is compact (46×38.5×13.5mm) and takes up little space. It is RoHS-compliant, non-toxic, and meets global environmental requirements for electronic products.
Applications
Home and Office: Enhances signal strength and stability for wireless routers, smart TVs, and desktop Wi-Fi cards.
Commercial and Industrial: Provides reliable WiFi connectivity for wireless access points (APs), surveillance cameras, and IoT gateways in warehouses, workshops, hotels, and other locations.
Outdoor and In-Vehicle Applications: Mounts quickly on vehicles, boats, or outdoor emergency communication equipment, securing quickly with a magnetic base to extend signal coverage.
Signal Dead Spot Remediation: Use a long cable to direct the antenna to a location with better signal quality, effectively resolving small indoor signal dead spots.
IoT Devices and Smart Home: Connect to various smart home hubs, smart appliances, and more to ensure stable network connectivity.
FAQ
Q: What Wi-Fi standards does this antenna support?
A: It covers the 2.4GHz band (2400-2500MHz), making it fully compatible with all Wi-Fi standards using this frequency band, including 802.11b/g/n/ax (Wi-Fi 4/6).
Q: Do I need to choose the connector type myself?
A: Yes, this antenna's connector is customizable. Please specify your device's interface model (e.g., SMA, RP-SMA, TNC, etc.) when placing an order to ensure perfect compatibility.
Q: Is the magnetic base strong enough? Will it fall off easily?
A: The base has a strong built-in magnet that sticks securely to flat metal surfaces. However, for applications involving severe vibration or uneven surfaces, we recommend evaluating the antenna before use or considering additional securing measures.
Q: What do the IP65-IP67 ratings mean?
A: IP65 indicates protection against dust and water jets, while IP67 indicates protection against dust and temporary immersion in water. This ensures the antenna can function properly outdoors in rain and snow (note that this rating does not include the cable outlet, which requires proper treatment).
Q: Is 3dBi gain high or low?
A: 3dBi is considered medium gain. It provides a moderate signal boost without overly narrowing the beam, making it a general choice for a balance between range and strength.
Q: Can it be used on 5GHz WiFi networks?
A: No. This antenna is designed for the 2.4GHz band. Using it in the 5GHz band will result in a significant performance drop because the antenna cannot resonate at that frequency.
