GL1200V8
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range- MHz | 1200-1700 |
VSWR | ≤1.5 |
Gain- dBi | 8 |
Horizontal beam width | 360° |
Verticalbeam width | 35° |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power- W | 50 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N male |
Dimensions- mm | Ф32 × 1800 |
Antenna weight- kg | 0.65 |
Radome material | Fiberglass |
Radome color | Gray |
Operating temperature | -40°c～60°c |
Rated Wind Velocity- m/s | 60 |
Mounting hardware- mm | ￠35~￠50 |
Product Introduction
1. Wide Frequency Range for Versatile Applications
This antenna operates within the 1200–1700MHz frequency band, making it suitable for various wireless communication systems that require stable and efficient signal transmission.
2. 360° Omni-Directional Coverage
With 360° horizontal beamwidth, the antenna provides full-area signal coverage, ensuring consistent connectivity for point-to-multipoint wireless networks.
3. High-Gain Signal Performance
Featuring 8dBi gain, the antenna enhances signal strength and extends communication range, making it ideal for outdoor wireless networking environments.
4. Durable Fiberglass Radome Design
The antenna uses a high-quality fiberglass radome, offering excellent resistance to UV, rain, and corrosion, ensuring long-term outdoor durability.
5. Reliable Operation in Harsh Environments
Designed for all-weather operation, the antenna works reliably in temperatures ranging from -40°C to +60°C and supports wind speeds up to 60 m/s.
Application Scenarios
1200MHz wireless communication systems
Point-to-multipoint wireless networks
Industrial wireless communication
Wireless monitoring and security systems
Base station signal coverage
FAQ
Q:What frequency range does this antenna support?
A:This antenna operates in the 1200MHz to 1700MHz frequency range, suitable for various wireless communication systems.
Q:What is the antenna gain?
A:The antenna provides 8dBi gain, which helps improve signal strength and communication distance.
Q:Is this antenna suitable for outdoor installation?
A:Yes. The antenna features a durable fiberglass radome designed for long-term outdoor use in harsh weather conditions.
Q: What type of connector does the antenna use?
A:It is equipped with a standard N-male connector, widely compatible with RF communication devices.
Q: What type of coverage does this antenna provide?
A:This antenna provides 360-degree omni-directional coverage, making it ideal for wide-area wireless networks.
Q:What is the maximum input power of this antenna?
A:The antenna supports a maximum input power of 50W.
