GL-DY410L
Asialeren
8517710000
100pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Item | Specifications | |
Antenna | Center Frequency | 698~960/1710~2690MHz |
Polarization | Linear | |
Gain | 3dBi typ. | |
V.S.W.R | ＜3.0 | |
Impedance | 50Ω | |
Connector | SMA Male | |
Antenna Dimension-mm | Ø13*198 | |
Environmental | Operating Temperature | -40℃~+85℃ |
Vibration | 10 to 55Hz with 1.5mm amplitude 2hours | |
Environmentally Friendly | ROHS Compliant | |
Differences between similar antennas
P/N | GL-DY410L | GL-DY411 | GL-DY412 |
Gain | 3 | 2.5 | 2.5 |
V.S.W.R. | 3.0 | 2.5 | 2.0 |
Product Introduction
Broad Spectrum Coverage
Supports 698-960MHz + 1710-2690MHz – compatible with global 4G/LTE bands (B5/B12/B13/B2/B3/B7) for versatile deployments.
Industrial-Grade Durability
Operates in -40°C to +85°C extremes with vibration resistance (55Hz/2hrs) – ideal for harsh environments like vehicles or factories.
Simplified Integration
SMA male connector and linear polarization enable plug-and-play installation on routers, trackers, and IoT gateways.
Cost-Effective Reliability
ROHS-compliant design balances performance (<3.0 VSWR) and affordability for high-volume deployments.
Optimized for Non-Critical Applications
3dBi typical gain provides reliable connectivity for medium-range uses without complex beamforming.
Fleet Management: Vehicle trackers and telematics systems
Industrial IoT: Remote sensor monitoring in factories
M2M Communications: Vending machines/ATMs connectivity
Backup Cellular Networks: Failover for fixed-line systems
Rural Broadband: Low-cost LTE routers for remote areas
Q: Does this support 5G bands?
A: No – optimized for 4G/LTE bands up to 2690MHz (narrower than 5G’s 3400+MHz requirements).
Q: What’s the radiation pattern?
A: Omnidirectional (typical for linear-polarized dipoles), ideal for mobile/rotating equipment.
Q: Is an adapter needed for SMA female ports?
A: Yes – pair with SMA female-to-female adapter if device has female connectors.
Q: Weather resistance rating?
A: While not IP-rated, its operating temperature range (-40°C~+85°C) suits outdoor enclosures.
Q: Why choose linear polarization?
A: Matches common router/CPE antennas; ideal where device orientation is unpredictable.
Q: VSWR <3.0 – is that sufficient?
A: Yes for non-critical apps (vs. <1.5 for base stations). Higher VSWR may reduce efficiency by ~25%.
Q: Typical cable length?
A: Not specified – recommend 1-3m RG174/RG316 cables based on application (sold separately).
Q: Certifications beyond ROHS?
A: None listed – verify FCC/CE compliance with manufacturer if required.
