GL-DY463
Asialeren
8517710000
100pc
accepted
10000PC/days
| Quantity: | |
|---|---|
| PDF Export | |
4G Rubber Antenna | |
GL-DY463 | |
Electrical Index | |
Frequency-MHz | 700-2700 |
Gain- dBi | 5.0 |
VSWR | ＜2.5 |
Radiation | Omni |
Normal Impedance -Ω | 50 |
Polarization | Vertical |
Mechanical Index | |
Connector | TS9 |
Antenna Dimension-mm | Φ13*97 |
Radome Material | ABS |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋60 |
Humidity-﹪ | 5～95 |
| Difference index between product numbers (P/N) | |||
| Index/(P/N) | GL-DY463 | GL-DY418 | GL-DY431 |
| Frequency range-mhz | 700-2700 | 824-960 | 698-960/1710-2700 |
| Gain-dBi | 5 | 3 | 5 |
| Antenna Dimension-mm | Φ13*97 | Ø12.5*110 | Ø26.5*220 |
Product Introduction
Wideband LTE Coverage – Supports 698-2700MHz, compatible with 4G/LTE, 3G, and IoT networks globally.
High-Performance Gain – Delivers 3.0dBi gain with VSWR <2.0 for stable signal transmission and minimal loss.
Durable Rubber Design – ABS material with flexible rubber structure ensures resistance to vibration and harsh conditions.
Universal Connectivity – Features a TS9 male connector, widely used in routers, modems, and industrial devices.
Extreme Environment Ready – Operates in -40°C to +85°C and 5-95% humidity, ideal for outdoor and industrial use.
4G LTE Routers/Modems – Enhances signal strength for home/industrial routers and cellular gateways.
IoT & M2M Devices – Reliable connectivity for smart meters, asset trackers, and agricultural sensors.
Marine & Vehicle Communications – Weather-resistant performance for boats, fleet tracking, and RV internet systems.
Public Safety Equipment – Used in emergency radios, surveillance systems, and disaster recovery networks.
Remote Area Connectivity – Improves LTE reception in rural or low-coverage zones for telecom infrastructure.
Q:What frequency range does GL-DY463 support?
A:698-2700MHz, covering LTE bands like B12/B13/B5 (700MHz) to B7/B41 (2500MHz).
Q:Is this antenna waterproof?
A:The ABS material resists humidity (5-95%), but it’s not fully waterproof. Avoid submersion.
Q:What is the connector type?
A:TS9 male, compatible with most 4G modems and industrial devices.
Q:Can it be used for 5G networks?
A:No, it’s optimized for 4G/LTE and 3G. For 5G, check our mmWave antenna series.
Q:How flexible is the rubber design?
A:It bends up to 90° without damage, suitable for tight spaces or moving parts.
Q:What is the antenna length?
A:97mm (Ø13mm diameter), compact yet powerful for its size.
Q:Does it need a ground plane?
A:No, it’s a monopole design with 50Ω impedance, requiring minimal PCB integration.
