GL1722V15
Asialeren
8517710000
50pc
Accepted
10000pc/day
| Quantity: | |
|---|---|
| PDF Export | |
Electrical Specifications | |
Frequency Range-MHz | 1710-2170 |
VSWR | ≤1.5 |
Gain-dBi | 15 |
Horizontal beam width-° | 50 |
Vertical beam width-° | 42 |
Front-to-back ratio-dB | ≥17 |
Polarization | Vertical |
Input Impedance-Ω | 50 |
Maximum input power-W | 50 |
Lightning protection | DC Ground |
Mechanical Specifications | |
Input connector type | N-K |
Installation | Pole-holding |
Dimensions-mm | 760 |
Antenna weight-KG | 0.5 |
Radiating Element Material | AI |
Operating temperature | -40°C to +70 °C |
Differences between similar products
| P/N | GL1722V15 | GLY900 |
| Frequency-Mhz | 1710-2170 | 806-960 |
| Gain-dBi | 15 | 4 |
| Input connector type | N-K | N-K |
Product Introduction
1. High-gain and precise coverage
15dBi strong gain + 50°×42° narrow beam angle, the effective transmission distance is increased by 3 times, and the signal scattering interference is reduced.
2. Industrial-grade stability
-40℃~70℃ wide temperature range operation, DC grounding lightning protection design, 50W high power load, adapt to harsh outdoor environments.
3. Lightweight and sturdy structure
Aluminum alloy radiation unit, only 0.5kg/760mm ultra-compact design (40% lighter than traditional Yagi antenna), wind resistance reduced by 65%.
4. Ultra-low signal loss
VSWR≤1.5 (industry average ≥1.8), reducing 35% signal reflection loss, ensuring efficient transmission in the full frequency band of 1710-2170MHz.
5. Intelligent anti-interference design
≥17dB front-end ratio, effectively isolates background noise, vertical polarization reduces multipath interference, and improves WiFi/3G signal purity.
Application scenarios
1.Wireless network expansion: outdoor AP bridging / factory WiFi coverage
2.Remote monitoring system: forest fire prevention camera / oil field sensor data transmission
3.Signal relay enhancement: telecommunication signal dead angle compensation / emergency communication vehicle
4.IoT hub: smart farm sensor cluster / remote weather station
5.Special communication: drone ground station / ship-to-ship communication
FAQ
Q: Does it support 5GHz WiFi?
A: Only supports 1710-2170MHz (covering 2.4GHz WiFi), 5GHz requires other models.
Q: Is the beam angle of 50° suitable for long-distance transmission?
A: Narrow beam reduces signal diffusion, and the maximum transmission distance is 8km (line-of-sight environment + 30dBm transmission power).
Q: Is a lightning arrester required?
A: Built-in DC grounding lightning protection, but it is recommended to install a surge protector in areas with high lightning incidence.
Q: Does pole installation require accessories?
A: Standard U-shaped clamp, suitable for φ32-50mm columns, including anti-loosening nuts.
Q: Can it be used for 4G LTE?
A: Supports 2100MHz frequency band (Band1), compatible with mainstream 4G devices.
Q: Does 50W power require a heat sink?
A: Natural heat dissipation design, continuous full-load working environment temperature ≤55℃.
