GL868V-11
Asialeren
8517710000
| Quantity: | |
|---|---|
| PDF Export | |
Technical data | |
Frequency range | 820-890MHz |
V.S.W.R | ≤1.5 |
Gain | 11dB i |
Horizontal | 55° |
Vertical | 45° |
F/B Ratio | ≥16dB |
Polarization | Vertical |
Input impedance | 50Ω |
Max Power | 50W |
Lighting protection | DC Ground |
Mechanical data | |
Connector type | N female |
Mounting | Pole |
Antenna dimensions | 980× 185×50mm |
Antenna weight | 0.6kg |
Radiator body material | Aluminium |
Work temperature | -40°C to +70 °C |
Clap material | Aluminium |
Product Introduction
High Gain & Directional Performance: With an 11dBi gain and narrow beam widths (55° horizontal, 45° vertical), the GL868V - 11 focuses signals for long - range transmission, reducing interference and enhancing signal strength in targeted areas.
Wide Frequency Coverage: Operating in the 820 - 890MHz band, it supports multiple applications like European ISM band devices, LTE networks, and wireless monitoring systems, ensuring compatibility with diverse regional standards.
Stable Electrical Specifications: Featuring a VSWR of ≤1.5 and 50Ω impedance, it ensures efficient power transfer and minimal signal loss, delivering reliable performance for critical communication links.
Durable Aluminum Construction: Made with an aluminum radiator body and clamps, the antenna is lightweight (0.6kg) yet robust, capable of withstanding harsh weather conditions and prolonged outdoor use.
Easy Pole Mounting & Lightning Protection: The N female connector and pole - mounting design enable quick installation, while DC ground lightning protection adds safety for outdoor deployments.
Application scenarios
Enhancing cellular signal in rural or mountainous regions.
Supporting industrial IoT devices in extreme temperatures.
Boosting base station performance for telecom operators.
Emergency communication systems requiring reliable uptime.
FAQ
What frequency range does this antenna cover?
It supports 820-890MHz, suitable for GSM, LTE, and IoT bands.
Is it waterproof?
While not fully waterproof, its aluminum body resists corrosion and performs well in harsh weather.
What’s the maximum power handling?
Up to 50W, perfect for high-power transmission needs.
Does it include mounting hardware?
No, but it’s designed for standard pole mounting (hardware sold separately).
Can it work in freezing conditions?
Yes, it operates from -40°C to +70°C, ideal for extreme climates.
Is the polarization adjustable?
No, it’s fixed to vertical polarization for optimal signal alignment.
What connector type is used?
N female connector ensures secure, low-loss connections.
How does the lightning protection work?
DC grounding directs surges safely to earth, protecting connected equipment.
