868MHz Rubber Antenna | |
GL-DY412 | |
Electrical Index | |
Frequency-MHz | 868MHz |
Gain | 2.5dBi |
VSWR | ＜2.0 |
Normal Impedance-Ω | 50 |
Polarization | Linear |
Mechanical Index | |
Connector | SMA R/A male |
Antenna Dimension-mm | Ø10.2*106.5 |
Environmentally Friendly | ROHS Compliant |
Temperature-℃ | -40～＋88 |
Humidity-﹪ | 5～95 |
|
Product Introduction
Right-Angle SMA Connector
SMA R/A male design allows 90° cable routing for space-constrained installations in control panels and enclosures.
ISM Band Specialization
Precision-tuned for 868MHz frequency (EU IoT standard) with 2.5dBi gain + <2.0 VSWR - ideal for LoRaWAN and Sigfox devices.
Enhanced Durability
Thickened rubber housing (Ø10.2×106.5mm) withstands physical impacts and extreme temperatures (-40°C to +88°C).
Maintenance-Free Performance
UV-resistant rubber construction prevents cracking in direct sunlight while resisting humidity (5-95%) and chemical exposure.
Plug-and-Play Installation
Direct screw-mount via SMA connector to compatible devices - no brackets or adapters needed.
Application scenarios
• Smart Metering: Electricity/gas/water meters with wireless AMR
• Industrial IoT: LoRaWAN sensors in factories, warehouses
• Agricultural Tech: Livestock trackers, crop monitoring systems
• Smart City Infrastructure: Parking sensors, waste management
• Asset Tracking: Pallet/container monitors across Europe
Q: Why 868MHz specifically?
A: Primary ISM band in Europe for IoT devices (LoRa, Sigfox, Weightless). Not compatible with 915MHz (Americas).
Q: What's the advantage of SMA R/A?
A: Right-angle connector saves space in enclosures and prevents cable strain in vibration-prone environments.
Q: Suitable for outdoor use?
A: Yes - rubber housing provides IP54-level splash/dust resistance (not fully submersible).
Q: Compatible with LoRa gateways?
A: Perfect for end-node devices.
Q: Maximum cable length?
A: Antenna has integrated connector (no cable). Extend with RG174 up to 5m.
Q: Mounting options?
A: Threads directly into SMA female ports. For non-threaded surfaces, use adhesive base (sold separately).
Q: Certifications available?
A: ROHS compliant. CE, RED, and UKCA certifications provided upon request.
