Main Technical Specifications | |
Frequency Range（MHz） | 600-960/1710-2700/3300-3800/4000-6000MHz |
Gain(dbi) | 3dBi |
VSWR | ≤ 2.0 |
radioactivity | Omni-Direction |
Polarization Type | Vertical |
Input maximum power | 50W |
Input Impedance（Ω） | 50Ώ |
Connector | SMA Male |
Cable | RG174 |
Cable length | 3m |
Product Material | ABS |
Antenna dimension | Φ87x110mm |
Installation way | Magnetic |
weight | 490g |
Operation temperature | -40℃ to+70℃ |
Product Introduction
1. Ultra-wide frequency band coverage, fully supporting 4G/5G networks
Covering an ultra-wide frequency range of 600-960/1710-2700/3300-3800/4000-6000MHz, perfectly compatible with existing 4G LTE and future 5G NR networks, ensuring long-term usability.
2. Strong magnetic base, easy and stable installation
Utilizing a strong magnetic base design with an adsorption force of up to 490g, it can be firmly fixed to any metal surface on the vehicle roof. A 3-meter RG174 cable provides ample wiring space; installation and removal take only seconds.
3. Omnidirectional radiation mode, ensuring stable connection during movement
3dBi gain combined with omnidirectional radiation and vertical polarization characteristics ensures a stable signal connection while the vehicle is in motion, eliminating signal fluctuations caused by directionality.
4. Industrial-grade durable design, adaptable to harsh environments
The ABS shell, combined with an operating temperature range of -40°C to +70°C, can withstand extreme weather conditions and is designed for long-term outdoor vehicle environments. 5. High power handling capability to meet professional application needs. With a maximum input power of 50W and excellent performance of VSWR≤2.0, it ensures stable operation even in high-power communication scenarios, making it suitable for critical applications such as public safety.
Application Scenarios
Emergency Response Vehicles: Mobile communication systems for public safety vehicles such as police cars, fire trucks, and ambulances.
Commercial Fleet Management: Real-time positioning and communication systems for logistics fleets, taxi fleets, and buses.
Outdoor Adventure Communication: Mobile network signal enhancement for off-road vehicles and RVs.
Mobile Office Solutions: Remote video conferencing and data transmission for commercial vehicles and engineering vehicles.
IoT Data Acquisition: Equipment status monitoring and data feedback for special vehicles and construction machinery.
FAQ
Q: What frequency bands does this vehicle antenna support?
A: It covers 600-960MHz, 1710-2700MHz, 3300-3800MHz, and 4000-6000MHz, supporting all major 4G LTE and 5G NR bands.
Q: How strong is the magnetic base?
A: With a magnetic force of 490g, it provides a secure attachment to vehicle roofs even at highway speeds.
Q: What's the cable length and type?
A: It includes a 3-meter... RG174 cable with SMA male connector, offering flexibility for various vehicle installations.
Q: Is this antenna suitable for 5G networks?
A: Yes, it specifically supports 3300-3800MHz and 4000-6000MHz bands used by 5G NR networks.
Q:Can I use this antenna on any vehicle?
A: It works on any vehicle with metal roof surfaces. For fiberglass or composite roofs, additional metal grounding plates may be needed.
Q: What's the advantage of omnidirectional pattern for vehicles?
A: Omnidirectional coverage ensures consistent signal reception regardless of vehicle direction or movement.
